Author: Dave Gauer
Created: 2023-02-02
Updated: 2024-12-22

Note: This page is my personal journey to discover Forth
and put it in the context of computing history.
It is adapted from my
slides for a short talk.
I’ve done everything in my power to make this page scale up and down
for various screen sizes. I welcome suggestions and corrections for
both the content and display of this page.
Here’s my
contact page.

In the 1990s, Usenet
newsgroups
(wikipedia.org)
were where it was at.
For example, Linus Torvalds’s initial announcement of Linux was to
comp.os.minix in 1991.

The comp.*
(wikipedia.org)
groups and particularly comp.lang.* were great
places to learn about and discuss programming.
By the time I got there in the late 90s, Perl was a pretty hot topic,
especially as it took a dominant role in the early Web as the
dynamic page and form processing programming language via
CGI
(wikipedia.org).

There were programming resources on the Web, but nothing like what’s
available now!
To actually learn to program, I bought books,
and still do.

Usenet was where the community and folklore lived.

(The “Easter egg” in this drawing is alt.religion.kibology, which should
get a chuckle from old timers. The rest of you can look it up.)

Sharp-eyed Lisp-lovers and other mutants will perhaps recognize this thing
as the Y combinator expressed with lambdas.

The only time I understood this was when I completed
the book The Little Schemer by Friedman and Felliesen, which
walks you through creating it for yourself. It is a magical book and
I implore you to try it.

Mel was real and the Royal McBee RPC-4000 was real. Look at that teletype
(aka “teleprinter”). If typewriters and “Royal” together make a little bell
in your head go “bing” as your mental carriage hits the end of the page,
then you’re right: Royal McBee was a merger between the
Royal
Typewriter Company (wikipedia.org) and McBee, a manufacturer of accounting machines.

For a while, Royal was owned by the Italian typewriter company, Olivetti,
who also made some really interesting computers (wikipedia.org).

And then…

Now begins my quest to understand Forth.

Perhaps you’ve seen postfix or
Reverse Polish Notation (RPN)
(wikipedia.org)
before? The principle is simple: Instead of the usual “infix” notation
which puts operators between operands (3 + 4), RPN puts
operators after the operands ( 3 4 +).

RPN notation is one of the most visually obvious
aspects of the Forth programming language. But it turns out, RPN is
not what Forth is about or the reason Forth exists.
As we’ll see, the situation is reversed.

In fact, as you’ll see, my quest is mostly a series of incorrect
assumptions I made by looking at the language without the context
of history.

By the way, the HP-35 calculator (wikipedia.org) pictured here is really interesting.
In the early 1970s, HP had powerful desktop calculators.
Actually,
what they had were really programmable computers, but they still
called them calculators (wikipedia.org) for sales reasons.
But these were big desktop machines that ran off of wall current.

Putting all of that power into a “shirt pocket” calculator was
an astounding accomplishment at the time.
Legend has it that the
size of the HP-35 was based on the dimensions of Bill Hewlett’s
actual shirt pocket.
HP-35 calculators have been in space. They killed off the slide rule.

HP calculators are famous for using RPN syntax. If it weren’t for
these calculators, I suspect it’s likely that RPN syntax would be
virtually unknown outside of computer science.

RPN is considered to be highly efficient and,
being somewhat inscrutable to outsiders, highly geeky.

Let’s see a better example…

I’m being cheeky here. Users of bc, are hardly
noobs. But it is arguably even geekier to use the much
older dc program. bc was once just an
infix expression translator for dc to make it more
palatable for people who didn’t want to use RPN. Thus the gentle
teasing.

Besides using RPN syntax,
the dc calculator
(wikipedia.org) is completely programmable. Oh and it also happens to
be one of the very first Unix programs and pre-dates the C programming
language!

Anyway, the point here is that RPN syntax lets you express
nested expressions without requiring parenthesis to get the order of
operations the way you want them. This is one of the reasons RPN fans
(including those HP calculator fans I alluded to) are so enamoured with it.

In this example, we input 3, then 4. * multiplies them.
Now we have the result (12) available. But first, we input 5 and 6 and
multiply them with another * to also store that result (30).
The final + adds both stored results (12 + 30) and
stores that result (42).
Unlike an HP calculator, dc doesn’t show us any of the
stored results, including the last one until we “print” it with the
p command.

As it is known about
“ed, the standard text editor” (gnu.org), dc doesn’t
waste your VALUABLE time (or teletype paper) with output you don’t need!

So this relates to Forth how?

As you can see, someone sitting at a Forth interpreter
can perform this calculation exactly the same as with the dc
calculator (or an HP calculator).

Sharp-eyed readers will note that we print the result with a “.”
command rather than “p”. But that’s the only difference.

So Forth is like an RPN calculator? We input values and then
operate on them?
Well, that statement is not wrong

But does that mean we know what Forth is all about now?
If we know how to enter things in postfix notation, we “get” Forth?
No! Not even close…

The use of a data stack is probably the second most visible thing
about the Forth programming language.

A stack is a data structure often explained with a “stack of
plates” analogy. You PUSH a plate on the stack and you POP
a plate off the stack. The first item you put on the stack is
the last item out of the stack.

Above, we have an illustration of PUSH and two other common
stack operations:

• SWAP slides a plate out (very carefully) from the second
  position and puts it on top.
• DUP takes the top plate and duplicates it using
  kitchen magic and puts the replica on the top of the stack (in
  this metaphor, I guess an equal amount of matter is removed
  somewhere else in the Universe, but we try not to worry too
  much about that).

As you may have guessed, these four stack words (PUSH, POP,
SWAP, DUP) also happen to be Forth words.

Historical note 1: In the old days, people and computers just
WENT ABOUT SHOUTING AT EACH OTHER ALL THE TIME IN ALL CAPS BECAUSE
LOWERCASE LETTERS WERE TOO EXPENSIVE.

Historical note 2: When a computer asks, “SHALL WE PLAY A
GAME?” in all caps, you must answer NO, as we learned in 1983’s
WarGames (wikipedia.org)

Let’s see a stack in action:

Let’s revisit our math problem from earlier. This is the
Forth code on the left and the results on “the stack” on the right.

Rather than being concerned with the syntax or notation, we’re
now interested in what these operations are doing with our data
stack.

As you can see, entering a number puts it on the stack.
The math operators take two values from the stack, do something
with them, and put a new value back on the stack.

The ‘.’ (DOT) operator is different since it only takes one
value (to print it) and does not put anything back on the stack.
As far as the stack is concerned, it is equivalent to DROP.
As far as humans are concerned, it has the useful side-effect
of letting us see the number.

Now let’s see something you probably wouldn’t find
on an HP calculator. Something non-numerical…

Getting the joke here will require knowing
this English idiom (wikipedia.org).

Actually, this isn’t just a silly example.
Forth’s use of the stack can lead to a natural, if somewhat
backward use of nouns and verbs. (Kind of like Yoda’s speech habits.
“Cake you will dup, yes? Have it and eat it you will, hmmm?”)

There can, indeed, be some object named CAKE that we have
placed on the stack (probably a memory reference) which
can be DUPed, and then HAVEd and EATen.

It’s up to the Forth developer to make harmonious
word choices. It can get far more clever or poetic than my example.

Naming things is great.

But sometimes not naming things is even better.

(Hopefully your answer is “no” or the rhetorical question doesn’t work.)

But it’s funny how our programming languages often require us
to explicitly name intermediate results so that we can refer to them.
On paper, we would never give these values names – we would just happily
start working on the list.

Imagine, if you will, a factory assembly line in which
each person working the line is a hateful fussbudget who refuses to
work on the part in front of them until you name it. And each time the
part has been worked on it must be given a new name. Furthermore, they
refuse to let you re-use a name you’ve already used.

A lot of imperative languages are like that factory. As your
values go down the line, you’ve got to come up with nonsense names
like result2, or matched_part3.

Does your programming language make you do this?

(It’s almost as bad as file names used as a versioning
system: my_doc_new_v5.4(copy)-final2…)

Working without names (also known as implicit or
tacit or point-free programming) is sometimes a more
natural and less irritating way to compute. Getting rid of names can
also lead to much more concise code. And less code is good code.

Great, so stacks can be a very elegant way to handle expressions.

Have we “cracked” Forth yet? Now we know two things:
it uses RPN syntax and it is stack-based.

On this journey of Forth discovery, you’ll inevitably run into
the term “concatenative programming”.

What’s that?

An awesome resource for all things concatenative is
The Concatenative Language Wiki
(concatenative.org).
It lists many concatenative languages and has a page about Forth,
of course.

For the term “concatenative programming” itself, the Factor
programming language website has an excellent page defining the
term:
Factor documentation: Concatenative Languages
(factorcode.org).
And, of course, there’s the Wikipedia entry,
Concatenative programming language
(wikipedia.org).

I understand the explanations on these websites now, but
it took me a while to get there. Your journey may be shorter or longer.
Probably shorter.

Let’s see if I can stumble through it…

An applicative language has you apply a function to a value, which
returns another value. Using familiar Algol-like (or “C-like”, or
“Java-like”, or “JavaScript-like”) syntax, arguments are passed to
functions within a pair of parenthesis. In the above example, the
parenthesis end up deeply nested as we pass the output of one function
to another.

Unlike the math examples, where the infix notation looks more
natural to most of us than the postfix notation, the concatenative
example of this baking program looks more natural (at least in a
human language sense) than the inside-out function application
example, right?

(Of course, if you’re a programmer used to years of something like C
or Java or JavaScript, the inside-out parenthetical form will probably
seem pretty natural too. Well, guess what? Your mind has been
warped. It’s okay, mine has too.)

The point here is that concatenative style has us “composing”
functions (which you can think of as verbs) simply by putting them
in sequence. Each function will be called in that sequence.
The values that are produced at each step are passed along
to be consumed as needed.

No names (unless we want them), just nouns and verbs.

But that’s just the surface. It turns out this “concatenative language”
concept goes way past that…

Can Programming Be Liberated from the von Neumann Style? (PDF) (worrydream.com)
This paper is dense with notation and I haven’t personally
attempted to wade through it, yet. I’m sure it contains
many profound ideas.

I know just enough to believe I understand this paragraph from
the paper’s abstract:

“An alternative functional style of programming is
founded on the use of combining forms for creating
programs. Functional programs deal with structured
data, are often nonrepetitive and nonrecursive, are
hierarchically constructed, do not name their
arguments, and do not require the complex machinery of
procedure declarations to become generally applicable.
Combining forms can use high level programs to build
still higher level ones in a style not possible in
conventional languages.”

Perhaps you’ve heard of “functional programming?” As you can
see, that term was being used in 1977.

“Concatenative programming” came after. In fact,
Joy is where the “concatenative” description comes from!
(von Thun specifically credits Billy Tanksley for creating the term
“concatenative notation”.)

I can’t describe Joy’s genesis better than the man himself.
Here is von Thun in an interview about Joy:

“Joy then evolved from this in an entirely haphazard way:
First I restricted the binary relations to unary functions, and
this of course was a dramatic change. Second, to allow the usual
arithmetic operations with their two arguments, I needed a place
from which the arguments were to come and where the result was to
be put – and the obvious place was a stack with a few shuffling
combinators, originally the four inspired by Quine. Third, it
became obvious that all these combinators could be replaced by
unary functions, with only function composition remaining. Finally
the very different distinctively Joy combinators emerged, which
take one or more quoted programs from the stack and execute them in
a specific way. Along the way of course, lists had already been
seen as just special cases of quoted programs. This meant that
programs could be constructed using list operations and then passed
on to a Joy combinator.”

From A Conversation with Manfred von Thun (nsl.com), which is a really great read in its entirety.

As you can see, combinators are crucial in Joy.
Let’s take a moment to dive into those, because this is a pretty
fascinating avenue of computer science…

“Higher-order” just means functions that take other
functions as input and do things with them.

You can even have functions that take functions that take functions
and so on to do powerful things. But you’ll need to meditate on
them every time you have to re-read that part of your code.

map is one of the more common examples, so I’ll use it
as an example.

(The second example with the arrow function syntax works exactly
the same way, but more compactly. I included it to make the comparison
with Joy a little more even-handed. Feel free to pick a favorite
and ignore the other one.)

In the first example, we have familiar Algol-like
syntax with functions that take arguments in parenthesis.

Perhaps
map() is familiar to you. But if not, just know that
it takes two parameters like so: map(array, function).
The first parameter is implicit in these JavaScript examples, but it’s
there. The array object, [1, 2, 3, 4] calls its own
map() method. The second parameter is a function
(named inc in the first example and left anonymous in
the second), which will be applied to every member of the list.

The output of map() is a new list containing the
result of each application.

Notice how both JavaScript examples
have variables such as the parameter n and the result
bigger. This is an example of what I mentioned a moment
ago when discussing the advantages of stacks: “Traditional”
programming languages often make us name values before we can work with
them.

The syntax here may require a little explanation.
The square brackets ([]) are Joy’s
quote mechanism. Quotations are a lot like lists, but they can contain
programs as well as data.

In this case, the first quotation is the number list,
[1 2 3 4].

The second quotation is a program, [1 +].

As in the JavaScript examples, map takes two parameters.
The first is the function (or “program” in Joy) to apply, and the second
is the list to apply it to.

(It’s kind of confusing to talk about “first” and “second,” though
because that’s the opposite order in which we supply those
arguments on the stack…)

Note the lack of variables bigger or n.
Intermediate values just exist.

It looks pretty nice and neat, right?

This “point-free” style can be a blessing…
or curse. Unlike computers, human brains have a hard time juggling too
many things on the stack.

There seems to be a happy medium between named and unnamed. Also,
the point-free style seems to benefit greatly from short (even
very short) definitions to avoid mental juggling and greater
composibility.

If you have the slightest interest in Joy, I highly recommend
reading or skimming this delightful tutorial by Manfred von Thun
himself:
An informal tutorial on Joy
(hypercubed.github.io).

Note: I had a bit of a time actually running Joy to test out these
examples. Thankfully, I eventually ran into
Joypy (github.com),
a Joy written in Python. My Linux distro comes with Python installed,
so the whole process for me was:

git clone https://github.com/calroc/joypy.git
cd joypy
python -m joy
...
joy? [1 2 3] [1 +] map


Okay, that’s a glimpse.

But we’ve barely touched the conceptual power of combinators with our
map examples. Let’s go a little deeper on
this fascinating subject:

Here’s something from my bookshelf. It’s To Mock a Mockingbird
by mathematician and
puzzle-maker Raymond Smullyan. It uses puzzles involving birds to solve
logic problems and classify some well-known combinators.

It would be impossible to write a complete catalog of
combinators just as it would be impossible to write a complete
catalog of integers. They’re both infinite lists.
Nevertheless, some well-known combinators have been identified as
having special properties. In the book above, many of these have
been given the names of birds.

Remember, combinators are just “higher-order”
functions that take functions as input.
Well, it turns out these are
all you need to perform any computation. They can replace logical
operators and even variables.

What?!

Yeah, you can re-work any expression into a combinatorial expression
and completely replace everything, including the variables, with
combinators.

It’s kind of hard to imagine at first. But you can see it happen
right before your very eyes.
The mind-blowing tool on this page by Ben Lynn:
Combinatory Logic
(stanford.edu)
takes a term expressed in lambda calculus and replaces everything
with just two combinators, K and S.
(We’ll talk more about those two in just a moment because they
are super special.)

(Ben Lynn’s whole website is full of neat stuff like this.
If you’re looking to entertain yourself for any amount of time from
an afternoon to the rest your life, Lynn has you covered.)

So combinators share something in common with lambda calculus and
Turing machines. These systems provide all of the building blocks
you need to perform any
possible computation in the sense of the
Church-Turing thesis (wikipedia.org)
or “computability thesis”. (We’ve also discovered some problems
that are not computable and no system can compute
them like “the halting problem,” but these are pretty rare.)

It turns out that computation is a fundamental feature of
the Universe.
As far as we can tell, any universal system of computation is equally
capable of solving any computational problem. And once you realize how
little is required, you can invent a universal computer yourself!

Electronically speaking, this is the same principle
that allows a NAND gate to simulate all other gates. NAND gates are
a fundamental computational building block. You can make an
entire computer with nothing but NAND gates and that computer can
(slowly) solve any computable problem you can imagine.

Anyway, when we use combinators, this particular flavor of universal
computation is called
combinatory logic (wikipedia.org).

What do the building blocks of combinatory logic look like?

Let’s start small:

The simplest of all combinators is I, the “identity combinator”.
There are a ton of different ways to write this. In lambda calculus,
it looks like this: I = λx.

The way to read "(I x) = x" is: “I applied
to some object x results in…x.”

We say “object x” rather than “value x” because, being a
combinator, I could take a function as input as well as a
value. In fact, “object” is intentionally very abstract, so
x could contain a scalar value, or
list, or function, or another combinator, or anything.
Whatever that object is, I returns it.

Both of these take more than one parameter of input.
But if you’re used to Algol-like function syntax, the way this
works may be surprising.

Since it’s the simpler of the two, let’s use the K
combinator as an example:

The way to read “(K x y) = x” is:
“K applied to x yields
a combinator, which, when applied to y always
evaluates to x.”

(Programmers familiar with the concept of currying will see
that this is like the partial application of a function, where
a new function is “pre-baked” with the argument x. The
term “currying” is named in honor of mathematician
Haskell Curry
(wikipedia.org),
after whom the Haskell programming language is also named.)

The result is that K makes a combinator that
throws away any input and just returns
x. Weird, right? But it turns out to be useful.

K is super easy to write in a language like
JavaScript, which is also a nice choice because you can play with
it right in the browser console like I just did:

K = function(x){
  return function(y){
    return x;
  }
}

K("hello")("bye")

> "hello"


See how the result of K("hello") is a function that
returns “hello” no matter what you give it as input?

How about S? I’ll leave implementing that
in JavaScript as an exercise for the reader.
It’s clearly much more complicated since it has three levels of
“function that yields a combinator” on the left and the result
is an equally complicated combinator that first applies
parameter z to combinator y.

(By the way, the y combinator above should not be
confused with the Y combinator.
Do you remember that arcane lambda calculus artifact projected
over that head with the third eye way up near the beginning of this
page? That thing was the Y combinator! It turns out, it’s
all, like, connected, you know?)

But the real point is this: S and K are
special for one very interesting reason.
Together with I, they form the “SKI calculus” and just
these three combinators are all you need to perform
any computation in the known universe.

Actually, it’s even crazier than that. You don’t even need
I because that, too, can be created with S
and K.

That’s right, the S and K definitions
above are a complete system for universal computation.

The book shown here is another from my bookshelf. It’s
Combinators: A Centennial View by Stephen Wolfram.

It starts with a (much too) terse introduction to the SKI combinator
calculus and then launches into page after page of visualizations of S
and K combinators being fed into each other. Like fractals or automata,
simple inputs can produce patterns of surprising sophistication.

Wolfram demonstrates combinators that keep producing different
output for a gazillion iterations and then get stuck in a loop. Some of
them produce regular patterns for a while and then start producing
different patterns. Some just loop forever at the outset.
As in other universal systems, there is no end to the complexity
produced by these two simple constructs. It is infinite. And all of
this is just S and K combinators taking combinators as input and
returning combinators as output.

I think it is wild and fun to see someone play
with a subject like Wolfram does in this book. Each page is saying,
“Look at what is possible!”

Combinators is also Wolfram’s ode to the discoverer of
combinatory logic,
Moses Schönfinkel (wikipedia.org)
who, like so many of the giants in the field of computer science,
did his work on paper decades before the first digital electronic
computers beeped their first boops.

Figuring out the output of the S combinator once
was enough to keep me occupied for a while. It boggles my mind to
imagine feeding it another S as input on paper,
let alone discovering these particular combinators in the first place.

Okay, we get it, combinators are a crazy way to compute.

But are they worth using in “real” programs? In limited
doses, absolutely!

Both of those pieces of JavaScript give us the result of applying
the function bar() to an array foo.

I think map() is a great example of the power of
combinators to clean up a program with abstraction. Once you start
using simple combinators like this to abstract away the boilerplate
logic of yet another loop over a list of items, it’s hard
to go back.

My personal history with exploring higher order functions in
a production setting is through the
Ramda (ramdajs.com) JavaScript
library, which I discovered from the talk
Hey Underscore, You’re Doing It Wrong!
(youtube.com)
by Brian Lonsdorf, which is fantastic.

Once I started discovering how combinators and curried functions
could eliminate big old chunks of code, I was hooked!
The old, dreary procedural code became a new fun puzzle!

Mind you, it’s very easy to go overboard with this stuff and
write something far less readable
than some simple procedural code. (Gee, ask me how I know this.)

But in limited doses, it’s super powerful and compact.

Computing the factorial of a number is often used as an example of
recursion. The final answer is the input number multiplied by the
previous number multiplied by the previous number multiplied by…
the rest of the numbers all the way down to 1.

Computing a factorial requires a cumulative result. Without
recursion, you need an explicit variable to hold the intermediate
result as you loop through the numbers.

As shown in the Joy factorial definition above,
linrec is a “linear recursion” combinator. It takes takes
4 parameters, each of which is a quoted program. null is a
predicate which tests for zero. dup is the same as in
Forth. pred is an operator which yields a number’s
predecessor (given 4, yields 3). “*” multiplies two
numbers, just like you’d expect. Given these pieces, perhaps you can
take a guess at how linrec works?

For comparison, here is a recursive JavaScript solution:

function factorial(n) {
    if (n <= 1) {
        return 1;
    }

    return n * factorial(n - 1);
 }


Note that the Joy example is not just shorter and has no
variable names but it has abstracted away the mechanics
of recursion. All we're left with is the
logic specific to the factorial problem itself.

It's debatable which of these two are more readable
because the measure of readability is in the eye of the beholder.
But I think you can imagine getting good at reading the Joy
example.

Okay, so we've gone pretty deep into this concatenative
programming and combinator thing. How does this actually
relate to Forth?

First of all, Forth does have facilities for
dealing with combinators:

First, let's see how EXECUTE works. The syntax will be
alien to non-Forth programmers, but the concept will be no problem for
anyone used to using first class functions.

First, let's make a new word:

: hello ." Hello" ;


This is Forth for, "Compile a word called hello
that prints the string Hello."

(We'll learn how compiling words actually works later.
For now, please just gracefully accept what you're seeing.)

Next:


VARIABLE hello-token


This creates a new variable called hello-token which
will store the "execution token" for the hello word.

This part will look super cryptic if you're new to Forth:


' hello hello-token !


Let's examine this one piece at a time:

• "'" gets the address of the word
  "hello" and puts it on the stack.
• "hello-token" is a variable, which
  just leaves its address on the stack when called.
• "!" stores a value from the stack
  (the address of hello) at
  an address from the stack (the address of
  variable hello-token).

So the code above simply reads, "Store the address of
hello in the variable hello-token."

Now let's use EXECUTE to call this "execution token":


hello-token @ EXECUTE
Hello


Behold, it printed the "Hello" string!

Remember, the variable hello-token leaves its
address on the stack when it is called.

"@" is a standard Forth word that loads the value
from the given address and puts that value on the stack.

EXECUTE gets an address from the stack and runs
whatever word is found at that address.

Perhaps it would be helpful to see that this silly statement:

' hello EXECUTE


is equivalent to just calling hello directly:

hello


Anyway, now we're armed with Forth's combinatorial ability:
Treating functions ("words") as values so other functions can
take them as input. This allows us to define combinators in Forth.

For some compact higher-order function definitions
in Forth, check out this Gist by Adolfo Perez Alvarez (github.com).

While both languages share a cosmetically similar syntax,
and both produce the same result for this
expression, there is a fundamental difference between how the two
languages "think" about the expression because they arrived at
this place in completely different ways.

Forth's only concern (as a language) is to process these three
tokens and act upon them according to some simple rules.
(If the token is in the dictionary, execute it. If it's a number, put
it on the stack.)

To Joy, it may be the same mechanical process under the hood, but
the language itself sees these tokens more like a mathematical
expression. It's a much more abstract outlook.

The point I'm making is that Forth may accomodate the
abstract point of view, if the developer chooses to take it. But
Forth is not based on abstract concatenative computing
principles or combinatory logic.

Let's look at this from a historical perspective.
First, the notions of postfix syntax (RPN) and a data stack for
the basis of the language:

Hold that thought, here's a fun aside:

The drawing of the computer labeled "Z3" on the right is of
the
Z3 computer
(wikipedia.org)
designed by engineer and computer scientist Konrad Zuse. This is widely
considered to be the first programmable digital computer!
It used electro-mechanical relays like the telegraph networks of the day.

(By the way, a certain amount of electro-mechanical logic is
still used in modern nuclear reactor safety systems because
the big mechanical components are not as vulnerable to nuclear
radiation as semiconductors!)

The Z3 could do addition in less than a second and multiplication
in three seconds. It had 64 words of 22 bits each and worked with
the equivalent of modern floating-point numbers.

As mentioned above, it can be said to use RPN, though there are only
two registers and nine instructions. Opcodes were encoded in eight
bits. The computer is programmable via punched paper tape (you can see
the tape device to the right of the control console, though it's a bit
of a scribble in my drawing).

It is also a stack machine. Again, this is with a mere
two registers, which get juggled in a particular sequence as you
load and store values.

Fun fact: The control unit used special control
wheels to encode microsequences. If the microsequence wasn't
programmed correctly, it could short-circuit the machine and destroy
the hardware!

I got most of this information from this excellent paper by
Raul Rojas:
Konrad Zuse's Legacy: The Architecture of the Z1 and Z3 (PDF) (ed-thelen.org).

Anyway, so the simple mechanics of RPN and stack-based
operation are very natural for digital computing machines
and their use goes back to the very beginning.

Uh oh.

While the ideas of combinators and other types of
universal computation were well known in certain mathematical
and computational circles, I would argue they were not very amenable
to existing computer hardware until much later when computers became
fast enough to support "functional programming" styles and
abstractions.

Until then, programming was "close to the metal."
Even the idea of "structured programming" with programming language
concepts like if/else or while/for loops was
once considered novel! Until then, everything was done with address
jumps or GOTO.

It's important to remember that "coding", the
actual act of turning an abstract program into machine code,
was long ago considered to be a mere secretarial skill, not far
removed from typing and other forms of data entry.
This is why some people (including myself) refer themselves as
"programmers" rather than "coders".

Concatenative programming, with its emphasis on combinators
(and immutable data structures, which we haven't talked about),
doesn't have the same historic grounding for Forth the way that RPN
syntax and stack-based programming do.

So I must conclude that understanding concatenative programming
is super cool, but it doesn't actually help us understand the
true nature of Forth because it doesn't describe how Forth came to be.
It is not part of Forth's "origin story."

As we'll soon see, Forth really is about the "nuts and
bolts". You bring your own theories with you.

There's nothing wrong with thinking about Forth in these terms,
but it doesn't answer the "why" questions:

"Why does Forth have this syntax?"

"Why does Forth work this way?"

I think the answers to the "why" questions are best answered by
looking at when.

What is Forth's history, anyway?

In Forth - The Early Years (PDF) (worrydream.com), Chuck
Moore recites a fairly terse history of Forth, from the earliest
pre-Forths to the creation of the language standard.

(Note: Chuck mentions the Smithsonian Astrophysical Observatory
(SAO) and the Massachusetts Institute of Technology (MIT) in
roughly the same time period, and it's a bit difficult to be
entirely sure which part is talking about which organization. But
if you look at a map, SAO is at Harvard University. Harvard and MIT
are about a mile apart in Cambridge, Massachusetts. It's basically a
singular point if you zoom out a bit. So that helps explain the
overlap.)

The computer in question is the
IBM 704
(wikipedia.org)
It was one of those room-filling vacuum-tube computers with
tape drives the size of refrigerators.

The 704 was a fully programmable "modern" computer with
magnetic-core memory, multiple registers, a 36-bit instruction set, and
36-bit words ("word" as in native memory size for the processor, not
"word" as in Forth functions).

There were switches for each register on the control console, but
programs could be written to and read from paper punch cards.

It was very modern for the time, but...

"In its day, the 704 was an exceptionally reliable machine.
Being a vacuum-tube machine, however, the IBM 704 had very poor
reliability by today's standards. On average, the machine failed around
every 8 hours, which limited the program size that the first Fortran
compilers could successfully translate because the machine would fail
before a successful compilation of a large program."

It's difficult to imagine now, but changing parameters for a program,
re-compiling it, and running it again could take a day (assuming you
didn't make any mistakes).

So Chuck solved that irritation with an extremely clever solution:

Here's a quote from The Evolution of Forth (forth.com):

"Moore's programming career began in the late 1950s at the
Smithsonian Astrophysical Observatory with programs to compute
ephemerides, orbital elements, satellite station positions, etc.
His source code filled two card trays. To minimize recompiling this
large program, he developed a simple interpreter to read cards
controlling the program. This enabled him to compose different
equations for several satellites without recompiling..."

His free-form input format turned out, ironically, to be more
reliable for human use than Fortran, which required formatted
columns. (At the time, any mis-aligned columns in Fortran punchcard
input would require a re-run of the program!)

It was also faster and more compact.

These "programming the program" statements in Moore's simple
interpreter did not use keywords.
They were statement numbers encoded on a punchcard.

So, at last, we have discovered the true origin of the Forth
language: Moore wrote a simple interpreter to reduce waste
and tedium.

Already, Moore has exhibited the defining combination of traits
shared by great programmers around the world: Inventive and allergic to
tedium.

If it had stopped there, it would have been a clever trick and
perhaps worthy of a footnote in history.

But Chuck Moore did not stop there.

Now we head from Massachusetts to California where Moore found
himself at Stanford University where he received his BA in Physics
and started graduate school. He worked with Stanford's
Burroughs B5500.

Let's talk about the computer first:

The B5500 (or "B 5500" - the official manual puts a space between
the B and the number) was a solid-state computer. It was part of the
"second-generation" of computers
(wikipedia.org).
These computers had discrete transistors on circuit boards. By
contrast, the first generation before them used vacuum tubes
(like the aforementioned IBM 704) and the third generation
after them used integrated circuits.

In fact, the
Burroughs Large Systems
engineers were transistor computer pioneers.
And the B5000 series was a pioneering system.

Here's some more resources:

• Burroughs B5000 / B5500 / B5700 gallery
  (retrocomputingtasmania.com)
  - an awesome illustrated guide including a picture of the
  actual Stanford B5500.
• Burroughs B5500 Reference Manual (PDF)
  (bitsavers.org)
  - The entire 224 page manual that came with the computer.
• Early Computers at Stanford
  (stanford.edu)
  - a description of the computer itself and a brief summary
  of its use at Stanford.

And what exactly did Chuck Moore do with that B5500 machine?

(As we'll see, symbols like "+" and "-" are words in Forth.)

Moore worked on the Stanford Linear Accelerator
as a programmer. His focus was on steering the beam of
the electron accelerator.

The CURVE program was even more "programmable" than
his Fortran program at SAO. He took those ideas and
expanded them to include the idea of a parameter stack
and the ability to define new procedures.

This made the interpreter much more flexible and capable.

Aside: At this point, I also think it's interesting to
compare Moore's budding interpreter language with another interpreter
created specifically to be embedded in larger programs for controlling
them:
The Tcl programming language
(wikipedia.org).
27 years after Moore started his work, John Ousterhout created Tcl out
of frustration with ad-hoc, half-baked solutions in 1988 at Berkeley. The
name comes from "Tool Command Language". But the comparison
goes deeper than just the shared motivation. Tcl and Forth
have similar levels of syntactical purity and flexibility. Everything
in Tcl is a string! Both languages give the user the power to define
fundamental parts of the system, such as new control structures, in the
language itself. If this sounds interesting, you owe it to yourself to
play with Tcl for a while. It is extremely clever and extremely
capable. The main implementation has been well cared-for and can be
found on most Unix-like systems, often installed by default.

As Moore demonstrated with CURVE, a powerful, extensible interpreter
is a huge time-saver (certainly when compared to re-compiling the
program!) and allows the user of the program to add to the program's
functionality on the fly. It's difficult to overstate how powerful this
can be.

Truly, now we have the beginnings of a fully-fledged
programming language. It's not named Forth yet, but
we're getting closer.

First, let's talk about what "TTY" means in 1965.
Teleprinters
(wikipedia.org) or "teletypewriters" or just "teletype"
were all printer devices. They printed to continuous sheets of paper
fan-folded to fit into boxes.

The Latin "tele-" prefix means "far" or "at a distance". These
machines trace a direct lineage from telegraphs and Morse code.

In the late 1800s, the concept of a typewriter which operated over
telegraph lines had been explored and existed in a variety of forms.
But the transmission code, paper tape, and typewriter system devised by
Donald Murray (oztypewriter.blogspot.com)
is the one that won out. And it was arguably Murray's
choice of QWERTY keyboard that cemented it as the standard around
the world.

The existing Baudot code (from which we also get the term "baud")
was modified by Murray into something that very much resembles what we
still use today. Murray also introduced the concept of control
characters, which still clearly retain their typewriter origins in the
names:
CR (carriage return) and LF (line feed).

Teletype machines started as point-to-point text communication
tools (like the telegraph), but they were later used over switched
networks like the world-wide Telex system which used pulse dialing
to automatically route a connection through the network.

The Teletype Model 33
(wikipedia.org)
I drew above was one of the most popular teletypes used with computers.
It was created by The Teletype Corporation in 1963, which means it
shares a birth year with the ASCII standard! It remained popular until
the mid-1970s when video terminals finally came down in price enough to
push printer teletypes aside. In fact, Teletype Co. made the Model 33
until 1981, which is much later than I would have guessed!

As for
paper-tape
(wikipedia.org), I'll just quote Wikipedia directly:

"Punched tape was used as a way of storing messages for
teletypewriters. Operators typed in the message to the paper tape,
and then sent the message at the maximum line speed from the tape.
This permitted the operator to prepare the message "off-line" at
the operator's best typing speed, and permitted the operator to
correct any error prior to transmission. An experienced operator
could prepare a message at 135 words per minute (WPM) or more for
short periods."

Donald Murray didn't invent the concept of perforated paper
tape for data storage, but his system used it for the encoding of
transmitted messages from the keyboard. It doesn't seem like a stretch
to trace the origins of this storage method to Murray's system.

The computers of this era and earlier were paper manipulators.
They were kind of like really complicated typewriters. They displayed
their output on paper, they were programmed with paper, and they kept
long-term storage on paper!

But as time went on, computer interactivity increased. They became
less like typewriters and more like the machines we use today.

As each new ability emerged, Forth became increasingly interactive.

In the mid-1960s, "mini-computers" came out. They were
still huge by today's standards, but no longer required a
large room of their own.

In addition to the reduction in size, the other emerging change was
direct interactive use of a computer via teletype.

Specifically, the invention of
timesharing (stanford.edu)
was a huge shift away from the "batch processing" style of
computing that had come before (like with input via punchcard).

(Fun fact: A "second generation" time-sharing operating system
called Multics
(multicians.org)
was the spiritual ancestor of and
name from which Brian Kernighan made the joke name
Unix: "One of whatever Multics was many of".)

Moore's evolving pre-Forth language also gained
completely interactive editing and executing of programs.

This would have been right around the time
that the original
LISP REPL (Read-eval-print loop)
(wikipedia.org)
was created in 1964 on a PDP-1.

If not pre-saging, Moore was certainly on the bleeding edge
of interactive computer usage!

Aside: If you want to see an awesome demonstration of
interactive computer usage on paper, check out this demonstration
by Bob Spence:
APL demonstration 1975
(youtube.com).
Bob Spence
(wikipedia.org)
is best known for his own contributions, including a number of early
clever computer interaction ideas that are worth re-examining today.
Bob's demo is extremely pleasant to watch and brilliantly presented
in split screen. Notice how paper output lets you mark up stuff with
a pen - pretty nice feature!
And
APL
(wikipedia.org)
is a whole other rabbit hole which has interesting intersections with
the point-free and higher-order function programming we've encountered
earlier.

Then this happens...

Yup, this really is the origin of the name, "Forth". Funny how
temporary things tend to stick and last forever, isn't it?

The
IBM 1130
(wikipedia.org)
is one of those new-fangled "minicomputers" we've talked about.
Gosh, it was so small, the CPU weighed less than a car!

And it was affordable! The base model was as low as $32,000.
Compare that to $20,000, the median price for a house in the U.S.
in 1965.
Just think of that: If you could afford a house, you were well
on your way to being able to afford a computer!

As noted, the unit Chuck Moore worked on had a disk drive,
which would have bumped up the price an additional $9,000.
That would be the equivalent of buying an above-average house
and adding a couple brand-new 1965 cars in the driveway.

But, wow, imagine having disk drive cartridges with 512 KB of
storage at your disposal. What would you do with all that space?

As mentioned, at this time, we're still interacting with the
computer (mostly) via paper, but these minis brought the idea of
interactive computing to "the masses" because they were so much
smaller, cheaper, and more reliable than the sorts of computers that
had come before.

Quoting
The Evolution of Forth (forth.com):

"Newly married and seeking a small town environment, Moore joined
Mohasco Industries in Amsterdam, NY, in 1968. Here he developed
computer graphics programs for an IBM 1130 minicomputer with a 2250
graphic display. This computer had a 16-bit CPU, 8k RAM, his first
disk, keyboard, printer, card reader/punch (used as disk backup!),
and Fortran compiler. He added a cross-assembler to his program to
generate code for the 2250, as well as a primitive editor and
source-management tools. This system could draw animated 3-D
images, at a time when IBM's software for that configuration
drew only static 2-D images. For fun, he also wrote a version of
Spacewar, an early video game, and converted his Algol Chess
program into the new language, now (for the first time) called
FORTH. He was impressed by how much simpler it became."

As you may have gathered by now, Chuck Moore is a pretty
extraordinary computer programmer.

It turns out the IBM 1130 was hugely influential to a bunch of early
big-name programmers in addition to Moore. Something was in
the air.

In addition to its funny new name, Forth had also gained new
abilities:

It's not just the name that makes this the first real Forth:
A dictionary of named words which can be called interactively or
recursively in the definitions of other words is one of the
defining features of Forth. The ability to use words as building
blocks is the Forth language's primary abstraction.

In the example above, we've defined a word called DOUBLE
which duplicates the number on the top of the stack and adds the
two numbers together.

A second word called QUAD uses the previous definition
by calling DOUBLE twice, quadrupling the number in a
rather amusing way.

A return stack makes this possible. Without a return stack, we have
no way of telling the computer how to "get back" to the place in
QUAD where we left off after DOUBLE is done.

(We'll get to the specifics of the syntax soon. That's another
vital part of understanding Forth.)

First of all, the UNIVAC 1108
(wikipedia.org)
is a great example of the awesome "retro-futuristic" design of
these old machines. Just look at the sweeping angles in my drawing
of the console. That's a cool computer console!

When these computers cost more than a house, it makes perfect
sense that they were constructed into beautiful custom furniture
that made them look like space ships.

You have to wonder: Did the sci-fi art of the time drive
the design of these computers or did the computers and industrial
design of the time inform the art? Or, more likely, did they both
feed off of each other in the classic cycle of, "life imitates art
imitates life?"

That's a teletypewriter built into the desk of the console.
I presume the tractor-feed paper would have spooled to and from
containers behind the sleek facade.

Anyway, the UNIVAC 1108 is an even more modern computer than the IBM
1130. Now we're moving into using integrated circuits for everything,
including the register storage. (Speaking of registers, the 1108 had
128 of them and must have been interesting to program!)

As was also the trend at the time, the CPU
was constructed of discrete cards connected together by a wire-wrapped
backplane.

If you're not familiar with the technique, you should know that
wire-wrapped
(wikipedia.org)
connections are extremely high quality. Wire is wrapped with
great force around a post, making a gas-tight connection that will not
corrode (corrosion can occur outside the connection, of course). A
little bit of the insulation gets wrapped in the last turns, which
provides flexibility and strain relief. There are NASA guidelines for
making a perfect wire-wrap connection.

Anyway, the Univac was even more powerful and modern
than Moore's previous computer and he took advantage of it.

You don't have to read between the lines to see Moore's obvious
distaste of
COBOL
(wikipedia.org),
the COmmon Business-Oriented Language.
What's impressive is that he managed to still use Forth while
also using the required COBOL modules.

When this project was abandoned by the employer, Moore was
upset by the whole situation, particularly the way business software
was increasing in complexity. This won't be the last time we
see this theme crop up.

He also wrote a book (unpublished) at this time called
Programming a Problem-Oriented Language.
It's written in typical Moore fashion, without superfluous words or
exposition. Feel free to contrast this with the article you're reading
now.

(This book will be mentioned again later.)

Radio telescopes are like visual telescopes, but they collect lower
frequency waves. Thanks to the magic of computers, we can process these
signals to see what the radio telescopes see.

Radio telescopes can work with everything from 1 kHz, which is just
below the uses of "radio" as we think of it for navigation,
communication, and entertainment, to 30 GHz, which is still well under
the visible portion of the electromagnetic spectrum. Consumer microwave
ovens operate at about 2.45 GHz.

(Speaking of Gigahertz, apparently Intel Core i9 processors can run
at clock speeds up to 6 Ghz, but most CPU designs top out at around 4
Ghz. This may be important for Forth for reasons I explain later.)

The visible part of the spectrum is very small by comparison. It
starts at 420 THz (terahertz) and ends at 720 THz. The familiar
rainbow of colors captured in the mnemonics "Roy G. Biv" or "Richard of
York Gave Battle in Vain" (ROYGBIV) lists colors in order of lowest
frequency (Red) to highest (Violet).

Here is the official website of the
National Radio Astronomy Observatory
(nrao.edu).
But for a better summary,
the Wikipedia entry (wikipedia.org)
is the way to go. Be sure to scroll down to the incredible image and
description from 1988 of the collapsed 300ft radio telescope:

"The telescope stood at 240ft in height, wieghed 600-tons, had a
2-min arc accuracy, and had a surface accuracy of ~1 inch. The
collapse in 1988 was found to be due to unanticipated stresses
which cracked a hidden, yet weight and stress-supporting steel
connector plate, in the support structure of the massive telescope.
A cascade failure of the structure occurred at 9:43pm causing the
entire telescope to implode."

The 300ft dish had been the world's largest radio telescope when it
went active in 1962 at the NRAO site in West Virginia.

My drawing above is of the
Very Large Array
(wikipedia.org)
in New Mexico.
NRAO is also a partner in a huge international array in Chile.

By using radio interferometry, arrays of telescopes can be treated
as essentially one huge telescope with the diameter of the array
(missing the sensitivity a dish of that size would have).

But the scope for which Moore wrote software was a single 36ft (11
meter) dish at Kitt Peak in Arizona called The 36-Foot Telescope.
It was constructed in 1967 and continued
working until it was replaced with a slightly larger and more
accurate dish in 2013.

The 36ft scope was used for millimeter-wavelength molecular astronomy.
This is the range above "microwaves" and these telescopes pretty
much have to be constructed at dry, high altitude sites because
water vapor in the air can interfere with the radio waves.

(Note that Moore stayed at the NRAO headquarters in Virginia and
was not on-site at Kitt Peak.)

NRAO had a policy of using Fortran on its minicomputers, but based
on the success of his previous work, Moore was begrudgingly given
permission to use Forth instead.
I couldn't possibly do justice to summarizing it, so here's Chuck's
own words describing the software he wrote for the NRAO (also from
Forth - The Early Years):

"There were two modes of observing, continuum and spectral-line.
Spectral-line was the most fun, for I could display spectra as they
were collected and fit line-shapes with least-squares."

It did advance the state-of-the-art in on-line data reduction.
Astronomers used it to discover and map inter-stellar molecules
just as that became hot research."

Here is a photo (nrao.edu) of the 36-foot telescope.
And
here is a photo of the control room in 1974
(nrao.edu)
with what appears to be a PDP-11 in the background.

As you can see, the work itself was extremely interesting and
cutting-edge. But how Moore went about it was also very interesting,
which a series of computer drawings will demonstrate in a moment.

But on the Forth language front, there was another development...

We take it for granted now that "free" or "open" software
unencumbered by patents and restrictive corporate licenses is a good
thing. But this was absolutely not a mainstream position in
the early 1970s.

To put things in context, in the summer of 1970,
Richard Stallman
(wikipedia.org) was just out of high school and was writing
his first programs in Fortran (which he hated) and then APL.

It wasn't until 1980 that Stallman finally got fed up enough with
the state of proprietary and legally encumbered software to start the
"free-as-in-freedom" software revolution. Companies were increasingly
using copyright to prevent modification, improvement, or duplication by
the end user. Stallman, being a pretty incredible programmer, wrote free
clones of such programs. He announced the
GNU project
(wikipedia.org)
in 1983.

Aside: I believe Stallman was right. There's absolutely
nothing wrong with writing programs for money or selling software. But
using the law to prevent people from truly owning that software
by limiting how or where to run it, or even preventing people from
writing their own similar software, if they are capable, is an
abominable practice and should be countered at every step.

"All of my fears of the standard and none of the advantages of the standard have come to pass. Any spirit of innovation has been thoroughly quelched.

Underground Forths are still needed.

I said I thought the standard should be a publication standard but they wanted an execution standard."

Quote from the ANSI Forth section in
this cool collection of Forth quotes
(ultratechnology.com) by Jeff Fox.

I think that when you get to the heart of what Forth is all
about, Moore's displeasure with the ANSI standardization suddenly makes
tons of sense. In short, the whole point of Forth is to create
your own toolkit. Having an all-inclusive language standard is great
for making sure Forths are interchangeable. Unfortunately, it's
also antithetical to adapting the language to your specific hardware
and software needs.

Alright, enough philosophizing. Let's get back to the computer
stuff!

While Moore was at NRAO, he also wrote software to point the telescope.
Elizabeth Rather (Moore credits her as Bess Rather in his paper) was
hired for support and they worked together on at least one port.
The Forth system migrated across multiple machines at NRAO which,
as we'll see, highlights one of the technological strengths of the
standard Forth implementation.

By the way, after her initial reaction of shock and horror,
Elizabeth Rather embraced Forth. From
The Evolution of Forth
(forth.com):

"After about two months, Rather began to realize that something
extraordinary was happening: despite the incredibly primitive
nature of the on-line computers, despite the weirdness of the
language, despite the lack of any local experts or resources, she
could accomplish more in the few hours she spent on the Forth
computers once a week than the entire rest of the week when she had
virtually unlimited access to several large mainframes."

Rather went on to write the first Forth manual in 1972 and
write papers about it for the NRAO and other astronomical organizations.

Later, Elizabeth "Bess" Rather
(wikipedia.org)
became the co-founder of FORTH, Inc with Chuck and
remained one of the leading experts and promoters of the Forth language
until her retirement in 2006.

There's a great overview paper of the whole NRAO system by
Moore and Rather in a 1973 Proceedings of the IEEE:
The FORTH Program for Spectral Line Observing (PDF)
(iae.nl).

It includes a high-level description of the system with examples of
interactive Forth usage and a neat diagram on the first page, which you
can see in the screenshot.

As mentioned, Forth was ported to a bunch of different computers
at NRAO.

Let's take a look:

Moore mentions first having ported his Forth system to the
IBM 360/50
(wikipedia.org).

The System/360 (or S/360) computers were extremely successful,
largely because of availability, longevity, and compatibility.
IBM claims to be the first company to use
microcode
(wikipedia.org)
to provide a compatible instruction set across all S/360 computers
despite the hardware differences between models.

The cheaper 360 computers used microcode while the more expensive
and powerful machines had hard-wired logic. NASA even had some one-off
models of IBM 360 made just for them.

Until microcode came along, if you bought a "cheap" computer to get
started and then upgraded to a more powerful computer, you would have
to re-write your programs in a new instruction set. (If you happen to
have written your programs in a high-level language like Fortran, you
would still have to re-compile your programs from punchcards, and you
would need the Fortran compilers on both computers to be perfectly
compatible!) It's easy to see why being able to upgrade without
changing your software would have been appealing.

System/360 computers were
a "big bet" (5 billion dollars according to IBM themselves:
System 360: From Computers to Computer Systems
(ibm.com)) that nearly destroyed the company.
The bet clearly paid off because they made these machines
from 1964 to 1978.

Oh, and it wasn't just the instruction set that was compatible. The
360 computers also had standardized peripheral interfaces, which were
compatible between machines.
There was a huge market for peripheral devices. IBM
themselves made 54 different devices such as memory, printers, card
readers, etc. The 360 also spawned a whole third-party peripheral
industry, much like the IBM PC-compatible era that started in 1981 and
continues to the desktop computer I'm typing on right now in 2023.

Moore wrote Forth from scratch in S/360 assembly.

Then...

I drew Chuck behind the system in this one because I couldn't
bring myself to obscure an inch of that glorious pedestal console.

You can see the
Honeywell 316
(wikipedia.org)
and the brochure
(wikimedia.org)
image from which I made my drawing.

Just look at the space-age lines on that thing! It looks straight
out of a Star Trek set. Sadly, there's basically no chance the one
Moore actually worked on had this console. Less than 20 of them were
sold. But thanks to my drawing, we can pretend.

Beyond just its appearance, this particular console has a really
wild history. The extravagant gift company, Neiman Marcus, actually
offered the Honeywell H316 with this pedestal as a "kitchen computer".
It cost $10,000 and would have come with a two-week course to learn
how to input recipes and balance a checkbook using toggle switches and
lights to indicate binary data! (As far as anyone knows, none of these
were actually sold.)

The ad for the Honeywell Kitchen Computer was in full "Mad Men"
mode and was extremely patronizing, as was unfortunately typical for
the time. But if you can look past that, the whole thing is quite
funny:

"Her souffles are supreme, her meal planning a challenge? She's
what the Honeywell people had in mind when they devised our Kitchen
Computer. She'll learn to program it with a cross-reference to her
favorite recipes by N-M's own Helen Corbitt. Then by simply pushing
a few buttons obtain a complete menu organized around the entree.
And if she pales at reckoning her lunch tabs, she can program it to
balance the family checkbook..."

You can see a tiny scan of the original ad with a woman admiring
her new Honeywell Kitchen Computer that barely fits in her kitchen
here
(wikipedia.org).

But moving on from the pedestal...

The implementation of Forth on the H316 is considered to be the
first complete, stand-alone implementation because it was actually
programmed on the computer itself and was used to create other
Forths. It is at this point that Moore has achieved a fully
ascendant system.

But wait, there's moore...er,
sorry, more!

As is typical for a Chuck Moore endeavor, this
telescope application pushed other new boundaries:
The system actually ran across two computers (we're about to see
the second one) and gave real-time access to multiple astronomers.
Because it spread the load the way it did, there were no issues with
concurrency, which is something we programmers struggle with to this day.

This real-time control and analysis was basically a
luxury available on no other system at the time.
Even Honeywell, the creator of these computers, had only been able to
achieve the most primitive concurrency for them and it was
nothing like this.

As usual, Moore was right on the very crest of
computing with his ultra-flexible Forth system.

As mentioned above, the Forth system was also ported to the
DDP-116
(t-larchive.org).
and used with its "parent" system on the H316 featured above.

(The DDP-116 was originally manufactured by
Computer Control Company in 1965, but CCC was sold to Honeywell in 1966 and
became its Computer Controls division.)

The DDP-116 was a 16-bit computer (the first available for
purchase), but still part of that "second generation" of computers
we've mentioned before, with individual
transistors and components wire-wrapped together on huge circuit
boards. (Check out the pictures on the DDP-116 link above for all
sorts of excellent views of the insides and outsides of an example
machine and its peripheral devices!)
It happens to have also been a pretty rare computer. It didn't sell
in vast quantities like the IBM systems.

As you can see in the drawing, Chuck Moore began to grow in power as
his system evolved and this manifested in additional
arms! Or maybe I started to get a little loopy while
drawing old computers for these slides in the final evenings before I
was due to give my talk? I'll let you decide what is real.

But wait, there's one more!

The
PDP-11
(wikipedia.org) was by some measures the most popular minicomputer ever.

It was a 16-bit machine and had an orthogonal instruction set
(meaning the same instruction could be used in multiple ways
depending on the operand. This makes the mnemonics of the instruction
set smaller and more logical and much easier to memorize).
This was even more powerful because I/O was memory-mapped, so the
same instructions used to move values around in memory and
registers could also be used to transfer data to
and from devices.

All told, these conveniences made the PDP-11 fun to program!
Assembly language programmers rejoiced. The ideas in the PDP-11 spread
rapidly and are to be found in the most popular architectures in use
today. Compared to what came before it, PDP-11 assembly language will
look surprisingly familiar to modern assembly programmers.

The original machines were made starting in 1970 with
wire-wrapped backplanes and discrete logic gates.
Later models introduced "large-scale integration," which is a term
we'll see later, so hold that question!
These later versions of the PDP-11 were still being
made twenty years later in 1990! There are apparently still PDP-11s
performing crucial tasks today, with nuclear power plants being one of
the most prominent examples.

It's hard to see in my drawing, but the PDP-11 front panel is one
of the most iconic computer interfaces ever made. Hobbyists make
working models, including ridiculously cute and awesome miniature
versions. Here are two model versions - click on them to go to the
original wikipedia.org files, where you can admire their full beauty:

It would be difficult to overstate the impact of this machine.
Probably the most famous piece of software released on the PDP-11
was the first version of
Unix
(wikipedia.org)
that actually bore the name "Unix".

It was also the birthplace of the
C
(wikipedia.org)
programming language.
Dennis Ritchie ported Ken Thompson's B language to the PDP-11 to
take advantage of its abilities. Unix was then re-written in C
starting with Version 4.
So the Unix we know today and a large portion of the command line
utilities that are standard with a Unix-like system were programmed
on the PDP-11. (And you can thank Richard Stallman's GNU project for
freeing those for the masses. GNU stands for "GNU's Not Unix!")

You'll also note that Chuck Moore has gained his
fourth and final arm in my drawing above
("fourth," ha ha).
This may or may not reflect actual events.
Also, I'm not sure if Moore would have been using a video terminal at
that time. It's possible. DEC's first video terminal was the
VT05
(columbia.edu),
which came out in 1970.

Wait, aren't most programs composed of calls to subroutines?

That's true. The big difference is that
threaded code
(wikipedia.org) in this sense
doesn't actually contain the instructions to call the
subroutines. It stores just the addresses.
Therefore another routine is responsible for advancing
a pointer over the address
list and executing the subroutines.

Huh?

Yeah, there's no way around it, threaded code is complicated.

And indirect threaded code is even more complicated (and
harder to explain).

"Hey, wait!" I hear you saying. "If Chuck hates complexity so
much, why did he use such a complex method for Forth?"

That's completely fair.

But before we address that, I'll try to briefly explain how
threaded code is stored and executed.

First, here's how normal machine code might be written:

This is the simplest type of "call" to store in a program.
We simply have the jmp (jump) instruction followed
by the address to jump to.
Here I show both a hard-coded address
(0x0804000) and a register
(eax).
Both of these are "direct" for our purposes.

Alternatively, many processors have a more advanced call
instruction. A call is more complicated because it has to do additional
work behind the scenes. It must store a return address on "the stack"
before jumping to the specified address. Then a ret
(return) instruction at the end of the called routine can use the
stored address to resume the execution just after the "call site" where
the call was first made. Why are return addresses stored on a stack?
That's because you can nest calls. Pushing addresses as you jump and
popping them in reverse order as you return keeps things nice and neat.
This "the stack" is not what Forth refers to as "the stack". Forth's
main stack is better known as "the parameter stack". Many Forth
implementations also have a return stack!

Anyway, this is direct and it's not threaded. Just jump to an address.

The first step of complication is adding indirection.

For this example to make sense, you need to know that the
square brackets around the register ([eax])
is a common assembly language convention that means
"the value at the memory address that is stored in register eax".

So jmp [eax] means "jump to the address
stored at the address stored in register eax."

That's indirect.

So now we have the "indirect" part of "indirect threaded
code." But what's the "threaded" part?

Instead of containing the actual instructions to jump or
call subroutines:

jmp 0x0804000
jmp 0x080A816
jmp 0x08C8800
jmp 0x08C8DD0


Threaded code stores just the list of
addresses:

0x0804000
0x080A816
0x08C8800
0x08C8DD0


There are two consequences of storing code like this:

• The address list takes up less memory than the full code to
  make the jump. (In fact, it takes a lot less on some
  historic machines.) This is good.
• Some sort of "code interpreter" will need to be written to
  execute this list. You can't just send a list of addresses
  to a processor and expect it to work. This could be good or bad.

Another way to look at the list of addresses above is that,
conceptually, threaded code is basically a list of subroutines.

To complete our definition of "indirect threaded" code, we just
need to put both concepts together:

This is where it gets pretty crazy. So now we've got a second
level of indirection. Why on Earth would we do this?

Well, this allows us to store a separate "code interpreter"
(or "inner interpreter") for different kinds of subroutines!

Instead of pointing directly at subroutines, these addresses point
at interpreters.
Talk about ultimate flexibility - every subroutine in an indirect
threaded program can have its own custom interpreter for the rest
of its instructions...each of which can also be threaded...or
indirectly threaded!

But what calls all of these inner interpreters?
An outer interpreter, of course! The outer interpreter is the
part we actually interact with when we sit down to type
at a Forth terminal.

In Forth, indirect threaded code is a list of
addresses pointing to the "inner interpreter" portions of
words, which execute the rest of the word.
What types of inner interpreters could we have, anyway?
Well, for example, we might have one kind of word that stores a string
in memory and another that executes machine code. But the only
limit is your imagination.

Make sense?

I personally would not have understood
that explanation at all until much later in my journey (I know this
because similar - probably better - explanations flew right over
my head). No doubt you're faster than me at apprehending this stuff
and are already halfway through implementing your own Forth based on
these descriptions.

None of the rest of the material requires understanding any
of the above, so please don't feel you need to fully
grok
(wikipedia.org)
it before continuing. Indirect threading is an important part of
Forth's history, but there are plenty of Forths that do not use it.

In addition to its compact storage, threaded code
would have been even more efficient on the contemporary
machines during Forth's gestation because
calling subroutines often wasn't as simple as the
call instruction found on "modern" architectures.

Subroutine and procedure call support
(clemson.edu) by Mark Smotherman explains:

"1963 - Burroughs B5000 - A stack-based computer with support for
block-structured languages like Algol. Parameters and return address
are stored on the stack, but subroutine entry is a fairly complex
operation."

So the memory and performance improvements of this style of
subroutine call were potentially
very great indeed. This is one of the reasons for Forth's
legendary reputation for high performance.

We'll revisit this topic from another angle soon. But if you're
interested in these mechanics
(and want to see the origin of the boxes and arrows
drawings at the top of this section), check out this multi-part
article series for The Computer Journal,
MOVING FORTH Part 1: Design Decisions in the Forth Kernel
(bradrodriguez.com),
by Brad Rodriguez.

The important thing is that we've now fully traced the origins
of Forth from a simple command interpreter to the full-blown
interactive language, editor, operating system, and
method of code storage and execution it became.

At last! Now we can put it all together:

Forth is postfix because that's a natural
order for the computer and lends itself to an incredibly minimalistic
interpreter implementation: get the values, operate on them;

Forth is stack oriented because that's a
compact and convenient way to store
values without needing to add variables or name things;

Forth is concatenative because building a
language that can operate as a string of words is incredibly
flexible and can adapt to just about any programming style without
any help from the language itself. (And it turns out this is
especially true when you throw in higher-order functions);

Forth is interpreted because that is
interactive and allows the programmer to make fast changes on
the fly or simply "play" with the system. This is part of
Forth's adaptability and flexibility;

Forth is self-hosting because you can
bootstrap a Forth implementation from a handful of words
implemented in assembly and then write the rest in Forth;

Forth is extremely compact because machines at
the time had limited memory and this gave Forth an edge on
other interpreters (and even compiled languages!) on
mainframes and mini-computers.

Now that we have everything in historical context, I think it's
much clearer why Forth exists and why it takes the peculiar
form that it does.

None of this was planned. Chuck didn't sit down at a terminal
in 1958 and conjure up Forth. Instead, he grew a system to
serve his needs and to make use of new hardware as it was made
available.

Reading about Forth's history is a wonderful way to understand
what makes Forth special and what it's about.

But even knowing all of this, I was still a long way off from a true
understanding of how this all comes together in an
actual working system. I didn't really understand how it worked.
And I didn't understand what Forth was actually like to use
In other words, I still didn't understand Forth as a
programming language.

I've mentioned it before, but I'll point it out again. Notice the
phrasing "implement a Forth."

As we've established, Chuck Moore believes a Forth system is best
when it is custom-tailored to the system and task at hand. So it
should come as little surprise that writing your own Forth or Forth-like is
entirely "par for the course" in any would-be-Forther's quest to
discover the True Meaning of the language and enter the mystical realm
where All is Revealed.

Well, what else could I do?

Having no other clear course of study, I decided to heed the
wisdom of the crowd.

Presenting...

To really get to know it, I took Forth to bed with me.

I wrote
Assembly Nights
when I realized how much I was enjoying myself:

"Over the last three months, I've developed an unusual
little nighttime routine..."

I prepared myself for dealing with the JonesForth source
(i386 assembly language in the GNU GAS assembler)
by learning some assembly and Linux ABI basics.
JonesForth is 32-bit only and uses the Linux system call ("syscall")
ABI directly.

Then I spent roughly a year porting JonesForth into a complete
working copy in NASM assembler. (Yes, that's a "port" from one flavor
of i386 asm to another.)

I did a tiny bit almost every night. A lot of it was debugging in
GDB.

Here's the
nasmjf web page

In the process of writing the port, I learned how a traditional
indirect threaded Forth works.

And I learned that it takes time to absorb such a
twisty-turny method of code execution.

Especially if the x86 assembly language tricks are new to you like
they were for me.

One of the first things you encounter when you open up the
jonesforth.S (a single file which contains the assembly
language portion of JonesForth) are many ASCII art diagrams.

Richard W.M. Jones does an excellent job of walking you through
the workings of the interpreter and explaining the i386 instruction
set features he uses.

If the diagram above seems bewildering, I agree.

So, of course, I thought maybe I could do better...

After I was done with my port, I tried to make an ASCII art diagram
of my own to capture my new understanding.
In fact, this is one of several.

With the benefit of the distance of time, it is clear to me that
these things only make sense once you already understand them to
some degree. But the act of making them is extremely useful
for solidifying your understanding.

But wait, there's more!

Both ASCII art diagrams above are just part of the complete
indirect threaded execution system. They're just showing how the "inner
interpreter" works to execute Forth words.

Perhaps you recall from the section about indirect threaded code
above that the second level of indirection allows different
"interpreter" routines to execute different types of threaded
subroutines? Well, that's all those two ASCII diagrams are trying
show.

But when we say that Forth is an interpreted language,
this is not what we're talking about. There's also the "outer interpreter"
that the programmer interacts with.

In the vector image I made above for nasmjf, I attempted to map out
the whole thing in my own words.

If you take anything from this image, it's that
INTERPRET looks up words (functions) by name and calls
them by executing the interpreter routine whose address is stored in
the word (again, this is the indirect threading part). In turn, there
may be any number of interpreters, but the three main types used in
JonesForth are:

• Pure assembly language routines are their own interpreters.
• "Regular" Forth words use the DOCOL interpreter.
  DOCOL executes the rest of the threaded code in the word,
  most of which is just a list of addresses, but some of
  which will be data. This is the "normal" kind of threaded
  subroutine.
• Numeric literals have a tiny interpreter routine inline with
  the data that just pushes their value to the stack. Numeric
  literals don't have to be words, though, in JonesForth,
  they're just a bit of inlined machine code.

But even knowing this only helps to explain how code starts
executing. How does this type of Forth know what to run after a word is
complete?

Ah, for that we have this:

Notice the term "code word". That's the Forth term for words
written in pure assembly language.

Every code word has this macro at the end. (Some Forths actually
call a subroutine for this. JonesForth uses this two-line macro
because the action is so efficient in i386 machine code.)

Remember the list of addresses in the explanation of
"indirect threaded" code? This is how we execute them sequentially.

This implementation uses the i386 lodsd instruction
to take care of two operations in one: move a "double word"
from memory into a register, and then update another register
so that it points to the next "double" spot in memory.

(Rant: And a "double" is 32 bits on Intel chips for the really
annoying reason that they kept the definition of "word" at 16 bits
even as the platform moved to 32 and then 64-bit architecture. So
"word" on Intel architectures is a completely meaningless thing
that you just have to memorize as "16 bits" even though
"word" is supposed to be the native data size of the architecture.
And what's worse is that the tools for working with programs on
Intel chips like GDB then refer to everything with the
corresponding C names for everything, which naturally assumed that
the architecture names would be based on reality. But they aren't.
So terms like "double" and "long" are basically just absolutely
worthless legacy garbage to memorize and useful only to C and Intel
architecture veterans.)

Okay, so now the eax register points to the next
threaded subroutine address in memory. The jmp starts
executing whatever that points to, which will be the "inner interpreter"
for that subroutine.

Got that?

A lot of moving parts, right?

There's more:

Remember, there's two fundamental types of words in a
traditional Forth like JonesForth:
"Code" words and "colon" words.
Code words are primitives written in machine code. Colon words are
the "regular" words actually written in the Forth language.

These "colon" words (so-named because they are assembled
via the "COLON" compiler, which we'll talk about in a moment),
all end in the so-called EXIT macro.

The EXIT macro handles the return stack. Then
there will be a NEXT after that to conclude whatever code
word primitive we were in (we're always in at least one because the
"outer-most" interpreter is a code word primitive!), so the
process we described above will automatically start where we left off
at the "call site" of the word we
just finished executing.

If you weren't lost before, surely this will do the trick?

I do have another attempt to explain how this all nests in
a sort of indented pseudocode:

This nested view of the process is as close as I've ever been to
explaining (to myself) what the entire execution flow
looks like at a high level.

I'm sure every Forth implementer has their own mental model.

You'll notice we didn't even talk about QUIT.
Other than the name, that one's not nearly as bad - it's really
just the end of the outer interpreter loop.

(So, yeah, we have EXIT and
QUIT, neither of which leave Forth... Hey, it was the
1960s. Things were different then.)

Historical note: The above "Crazy Chuck" drawing is a parody of
a popular meme with actor Charlie Day's character in the episode
"Sweet Dee Has a Heart Attack" from the show It's Always Sunny
in Philadelphia:

"Every day Pepe's mail's getting sent back to me. Pepe Silvia, Pepe
Silvia, I look in the mail, this whole box is Pepe Silvia!"

You, citizen of the distant future, will not have recognized this
parody, but at least now you can look it up.

I'll repeat your question from before so you don't have to:

"Hey, wait! But if Chuck hates complexity so
much, why did he use such a complex method for Forth?"

This is where the historical context is, once again, very revealing:

As we've seen, Charles H. Moore did not create Forth all at once in a
single lightning bolt of inspiration.
It began as a simple command interpreter and executor and grew
from there.
It has always consisted of tiny little parts, working together.

Each of these tiny parts is extremely simple on its own.

And each was added over a period of time as the need arose.

I think that's the genius of Forth: That all of these little
pieces can work together to make a running system and yet still
remain independent.
You can learn each of these in isolation. You can replace them
in isolation.

Ultimate flexibility and simplicity at the lowest level of
the implementation comes at the cost of easy understanding at
higher levels.

When growing a system like this, most of us would have thought
bigger, Moore thought smaller.

Let's do the same.
I've thrown the terms "code word" and "colon word" around a lot.
I've explained them a bit, but we've never given a proper introduction.

Let's go small:

Again, Code words are primitives written in machine language
supplied by the Forth implementation.

Let's see some real code words so we can de-mystify them
once and for all. These are extremely simple
and extremely concrete examples of actual NASM assembly language source
from my nasmjf port of JonesForth:

Is that really SWAP? Yes, it really is! We're just telling the
CPU to pop the two most recent values from the stack and then push them
back in the opposite order.

(JonesForth uses the i386 call/return stack as a Forth parameter
stack so we can use the native "pop" and "push" to make these
operations easy. In exchange, we lose the ability to use "call"
and "ret" for subroutines.)

The DEFCODE macro is housekeeping - it creates the
entry's header in the Forth word dictionary.

Notice the NEXT macro we talked about previously?
Remember, that's just another two lines of assembly pasted at the
end of this routine.

We're down to just two instructions now! We move the value pointed
at by the esp register into eax and then push it onto the
stack.

To understand why this duplicates the top item on
the stack, you need to know how the esp register is used.
Here's the relevant comment from the JonesForth source:

"In this FORTH, we are using the normal stack pointer (%esp) for the
parameter stack. We will use the i386's "other" stack pointer (%ebp,
usually called the "frame pointer") for our return stack."

Which means that esp points to the current top of
the parameter stack. So pushing that value on the stack duplicates
the top value. (This could also have been written more clearly with
three instructions: one "pop" and two "push"es.)

Now we have an entire Forth word defined as a single
instruction! DROP just "removes" the top value from the stack. In this
case, we pop it into the eax register and then don't do
anything with it, essentially throwing it away. (Alternatively, we
could have decremented the esp register, but in this case,
the "pop" is both shorter and clearer.)

Now let's see these three words in action in a real
Forth program that moves some real numbers around
in memory...

The code word primitives we've just defined are used by the
rest of the Forth implementation to define colon words in the
language itself. If you write Forth applications, your own
colon words will probably use these heavily.

You can also call them interactively in the interpreter.

The above example shows what it might be like to use these
three primitives right at the keyboard. The column on the right
shows the state of the parameter stack after each line of input.

Apart from pushing the two numbers on the stack (8 7)
, we've now seen the assembly language code for the entire
program shown above. That makes this pretty "bare metal" stuff, right?

Here's the walk-through:

• We start with 8 and then 7 on the top of the stack.
• SWAP reverses the order of the stack so 8 is now on the top.
• DROP pops the 8 and throws it away. Now only 7 remains.
• DUP pushes a second copy of 7 onto the top of the stack.

Again, these instructions could exist in the definition of a word or
you could type them interactively in the running Forth interpreter.
The result is the same.

I think there's something pretty magical about realizing that
typing these instructions is running specific machine code
sequences exactly as they were entered. In this implementation,
there's no optimizing compiler or virtual machine acting as middle-man.
You really are communicating directly with the processor.

If you weren't already wondering, perhaps you are now:
How many Forth words need to be defined in machine code
to have a "bootstrappable" Forth system?

There are some theoretical minimums. But as you get down to an
absurdly small number of instructions, the Forth code written with the
primitives (to implement the rest of the language) approaches absurdly
large amounts of convolutions that test the limits of both programmer
ergonomics and computational inefficiency.

Check out this amazing article by Frank Sergeant:
A 3-INSTRUCTION FORTH FOR EMBEDDED SYSTEMS WORK
(utoh.org).

"How many instructions does it take to make a Forth for
target development work? Does memory grow on trees? Does the cost
of the development system come out of your own pocket? A 3-
instruction Forth makes Forth affordable for target systems with
very limited memory. It can be brought up quickly on strange new
hardware. You don't have to do without Forth because of memory or
time limitations. It only takes 66 bytes for the Motorola MC68HC11.
Full source is provided."

You read that right: 66 bytes.

And later:

"The absolute minimum the target must do, it seems to me,
is fetch a byte, store a byte, and call a subroutine. Everything
else can be done in high-level Forth on the host."

Which reminds me, did you know there is such a thing as a
one-instruction set computer
(wikipedia.org)?
And of course you can run Forth on them:
16-bit SUBLEQ eForth
(github.com).

But that's nuts.

How about something a little more realistic?

Cesar Blum's
sectorforth
(github.com)
is:

"...a 16-bit x86 Forth that fits in a 512-byte
boot sector. Inspiration to write sectorforth came from a
1996 Usenet thread."

See? There's Usenet again. It wasn't just me reading all that lore.

The author's
posting of the project to the Forth sub-reddit
(reddit.com)
has additional insight:

"I've always been fascinated by the idea of having a
minimal kernel of primitives from which "everything" can be built.
Before Forth, I had only seen that in the form of Lisp's "Maxwell
equations of software", which is cool, but always left me a little
disappointed because it is too abstract to build something that you
can actually interact with - you can't break out of its esoteric
nature...

With Forth, however, you can start from almost nothing, and start
adding things like ifs, loops, strings, etc., things that look more
like your day-to-day programming. I find that there's a lot of
beauty in that."

Note: The statement about Maxwell's equations surely refers to
Alan Kay's famous quote about LISP from
A Conversation with Alan Kay
(acm.org):

"Yes, that was the big revelation to me when I was in graduate
school - when I finally understood that the half page of code on
the bottom of page 13 of the Lisp 1.5 manual was Lisp in itself.
These were "Maxwell's Equations of Software!" This is the whole
world of programming in a few lines that I can put my hand over."

Okay, so we've talked about code words
that are just chunks of machine code that can be called upon
at any time.

Now let's see what colon words are all about...

A colon word is so-named because its definition begins with the
":" character.

The example colon word definition above creates a new word called
SDD that is a composition of the three code words we
defined earlier: SWAP, DROP, and
DUP.
Perhaps the word "composition" brings to mind the concatenative
terminology we explored earlier in this quest?

As this example demonstrates, colon words are defined entirely
by other words, which may be code words or other colon words.
You can also have numeric values, e.g. 8 and 7, which
are handled by the interpreter.

(You can also have strings, which looks like data...but those are
just input that happens to follow one of the special words, e.g.
." (dot quote), that knows how to handle the input!)

Let's see it in action:

The effect of calling our new SDD word is, of course,
identical to calling the three separate words SWAP,
DROP, and DUP in sequence.

In indirect threaded code terms,
this colon word has been "compiled" into the addresses of
the "inner interpreters" for each of the three code words.
But feel free to ignore this detail!

Let's demystify this further because the Forth "compiler" is
probably much, much simpler than you'd think:

How ":" works

Here's what really happens when we enter this:

: SDD SWAP DROP DUP ;


Colon (:) fetches the word name (SDD) and sets "compile mode".

Semicolon (;) completes the word's entry in the dictionary and unsets "compile mode".

"Compiling" in Forth means putting one of two things into memory:

• The address of a word, or
• A value literal and a bit of code that pushes it on the stack

At its simplest, compiling is just like executing, but we're storing
addresses instead of jumping to them.

: SDD SWAP DROP DUP ;


Almost no syntax = simple interpreter and extreme extensibility

The tiny set of rules that govern the interpreter:

• WORD gets a token.
• Is it in the dictionary? (And are we compiling?)
• Is it a numeric literal? (And are we compiling?)
• Otherwise, error!

Let's look at our example code again. The first line
runs, the second line compiles:

8 7 SWAP DUP +

: SDP SWAP DUP + ; 8 7 SDP


The definition of IF...THEN from jonesforth.f:

: IF IMMEDIATE ' 0BRANCH , HERE @ 0 , ;

: THEN IMMEDIATE DUP HERE @ SWAP - SWAP ! ;


'       - gets the address of the word that follows, put on stack
0BRANCH - branch to the next value if the top of the stack has 0
,       - 'compile' the current stack value to the memory at HERE
@       - fetch value from address on stack, put value on stack
!       - store to memory (stack contains address, then value)


The definition of ( ) nested comments from jonesforth.f:

: ( IMMEDIATE
    1
    BEGIN
        KEY DUP '(' = IF DROP 1+
        ELSE ')' = IF 1- THEN
        THEN
    DUP 0= UNTIL
    DROP
;

(
    From now on we can use ( ... ) for comments.
...


The Dictionary

A Forth dictionary traditionally uses a linked list.

Word matching is done starting from the end
(most recent entries) first, so:

• You can redefine any word, even the ones originally
  defined in assembly!
• Words depending on previous definitions of redefined words
  won't break because the compiled addresses still point to
  the original word, not the new definition!
• You are in complete control!
• Again, Forth = freedom!

It's not just the language itself that is unusually malleable.
Your program written in Forth can be flexible too.

Here is an example lifted and paraphrased from Thinking Forth
by Leo Brodie.

Say we create a variable to hold a number of apples:

VARIABLE APPLES
20 APPLES !
APPLES ? 20


Forth variables put addresses on the stack.

VARIABLE APPLES


20 APPLES !


APPLES ?


: ? @ . ;

We pepper our program with this APPLES variable.

The application works perfectly for a couple years.

Then we are told that we must now keep track of two different
kinds of apples: red and green. What to do?

A new variable will store the current type of apples.

VARIABLE COLOR


"REDS" will count red apples.
Colon word "RED" sets the current type of apple to red:
COLOR = REDS:

VARIABLE REDS
: RED REDS COLOR ! ;


void RED(){
    COLOR = &REDS
}


Same for green.

VARIABLE GREENS
: GREEN GREENS COLOR ! ;


void GREEN(){
    COLOR = &GREENS
}


Lastly, we change "APPLES" from a variable to a word that gets
the current count by color:

: APPLES COLOR @ ;


int *APPLES(){
    return COLOR;
}


Now we have to re-write any use of APPLES, right?

Wrong! The use of APPLES is identical. The syntax hasn't
changed one bit for any existing code. We just need to make sure we've
set the right color.

Check it out:

20 RED APPLES !
30 GREEN APPLES !

GREEN APPLES ? 30
APPLES ? 30

RED
APPLES ? 20


To Forth, it's all just words in a dictionary.
"VARIABLE" is just another word
you could have written yourself.

Implement a Forth to understand how it works

I highly recommend implementing Forth (or porting it like I did) to understand
how it works "under the hood."

But be aware of what this will not teach you

Implementing an interpreter teaches you almost nothing about how
to write programs with that interpreter.

Or invent Forth for yourself

"I didn't create Forth, I discovered it."

-- Chuck, apocryphally

Making nasmjf gave me so many ideas, I had to try some
experiments.

Forth is an amazing playground for ideas.

Meow5

An exercise in extreme concatenative programming where
all code is concatenated (always inlined).

pop eax


: meow "Meow." print ;
meow
Meow.

: meow5 meow meow meow meow meow ;
meow5
Meow.Meow.Meow.Meow.Meow.


Despite attempting to go my own way,
it's remarkable how many times Forth's solution was the
path of least resistance.

Again and again I would say, "Aha! That's why."

To make a string in Forth, you use the word ", which
needs a space after it to be seen as a word, which looks awkward:

" Hello World."


Meow5 has this more natural quoting style:

"Hello World."


But the effects are cascading. And they limit flexibility.

Another example of straying from Moore's advice
and having to discover it for myself:

I decided to have some of my functions leave the stack alone after using
the top value.

Now we have yet another reason for the title of this
article.

Once you start down the Forth path... the rest just sort of
"writes itself".
Chuck Moore already found the path of least resistance.

To sum up the ways in which "Forth writes itself" so far, we have:

• Forth is boostrapping
• Forth is metaprogramming
• Forth can be your OS and your IDE/editor
• Forth is the path of least resistance for writing a Forth

(
    ASSEMBLER CODE --------------------------------------------

    This is just the outline of a simple assembler, allowing
    you to write FORTH primitives in assembly language.

    Assembly primitives begin ': NAME' in the normal way,
    but are ended with ;CODE.  ;CODE updates the header so that
    the codeword isn't DOCOL, but points instead to the
    assembled code (in the DFA part of the word).

    We provide a convenience macro NEXT (you guessed what it
    does).  However you don't need to use it because ;CODE will
    put a NEXT at the end of your word.

    The rest consists of some immediate words which expand
    into machine code appended to the definition of the word.
    Only a very tiny part of the i386 assembly space is covered,
    just enough to write a few assembler primitives below.
)


PlanckForth

Hand-written 1Kb binary

h@l@h@!h@C+h!k1k0-h@$k:k0-h@k1k0-+$h@C+h!ih@!h@C+h!kefh@!h@C+h!l!
h@l@h@!h@C+h!k1k0-h@$k h@k1k0-+$h@C+h!ih@!h@C+h!kefh@!h@C+h!l!

h@l@ h@!h@C+h! k1k0-h@$ kh@k1k0-+$ h@C+h!
    i       h@!h@C+h!
    kkf     h@!h@C+h!
    kLf     h@!h@C+h!
    k:k0-   h@!h@C+h!
    k=f     h@!h@C+h!
    kJf     h@!h@C+h!
    k0k5-C* h@!h@C+h!
    kef     h@!h@C+h!
l!

 **Now we can use single-line comments!**

 planckforth -
 Copyright (C) 2021 nineties
...


Forth is an idea that has taken form in countless applications.

Many Forths are custom and home-grown.

But it has had great success in a huge variety of roles:

• Power plants, robotics, missile tracking systems, industrial automation.
• Embedded language in video games.
• Databases, accounting, word processors, graphics, and computation
  systems. (You might say, "legacy software." But I say, "Elegant
  weapons for a more civilized age," to paraphrase a certain wise
  Jedi.)
• In the modern Open Firmware boot loader.
• Processors of all shapes and sizes.
• Microcontrollers of all shapes and sizes.

Jupiter Ace, 1982

Operating system: Forth.

OS and library of routines in 8 KB of ROM.

The onboard Forth was "Ten times faster than [interpreted] BASIC" and
less than half the memory requirements."

Canon Cat, 1987

Operating system: Forth.

OS, office suite, and programming environment in 256 KB of ROM.

Innovative interface by Jef Raskin.

NASA and the ESA

The list of projects using Forth at NASA compiled by James Rash in 2003 is too long to easily list here.

Space Shuttle Small Payload Accommodations Interface Module (SPAIM)

"There is always great concern about software reliability, especially with flight software."

NASA's Robot Arm Simulator

Given the input of three-axis joystick commands, control a
50-foot long, six-joint arm with six different coordinate systems.

Entire system developed by one programmer in five weeks.

Shuttle Mission Design and Operations System (SMDOS)

JPL's ground-based control software for shuttle SIR-A and SIR-B
radar imaging instruments.

Forth hardware in space

The Harris RTX2010 processor. Used in a ton of space
applications.

Featuring:

• Direct execution of Forth
• Two hardware stacks, 256 words deep
• 8MHz clock, extremely low latency
• Radiation hardened

Rosetta and Philae

First mission to send a spaceship to orbit a comet and then deliver a
lander to the comet's surface!

The Rosetta spacecraft's Ion and Electron Sensor instrument used a Harris RTX2010.

The Philae lander used two Harris RTX2010s for complete system control (CDMS) and two more to control its landing system (ADS).

A picture taken by the Philae lander as it lay on its side, enjoying some sunlight on
one of its feet:

This is one of the final images taken by the Rosetta orbiter as it made the
"hard descent" (controlled crash landing) to the surface of comet 67p:

Stop Writing Dead Programs

"...Space probes written in Lisp and Forth have been
debugged while off world... If they had proven their programs
correct by construction, shipped them into space, and then found out
their spec was wrong, they would have just had some dead junk on
Mars. But what these guys had was the ability to fix things
while they are running on space probes... In addition, the spec is
always wrong!"

-- Jack Rusher, Stop Writing Dead Programs (talk given at Strange Loop 2022)

When we defeat the alien kill-bots and reprogram them, it will
surely be with a Forth of some sort.

BARREL OBJECT-ID VISION TARGET
133 L-ARM-FWD 14 L-CLAW-OPEN
25 L-ARM FWD 14 L-CLAW CLOSE


PREP-QUAD-LEGS
20 STRIDE-LOOP


: KILL
    100 BEAM-LEVEL
    BOT OBJECT-ID VISION TARGET
    L-BEAM FIRE-FULL
    R-BEAM FIRE-FULL
;


Forth is an idea

Here's a "family tree" of some notable Forths:

What about Chuck?

Charles H. Moore founded Forth, Inc in 1973. He's continued to port
Forth to various systems ever since. But he's never stopped inventing.

colorForth

The pursuit of simplicity

Chuck Moore has been fighting against software complexity since the 1950s.

"I am utterly frustrated with the software I have to deal with. Windows is beyond comprehension! UNIX is no better. DOS is no better. There is no reason for an OS. It is a non-thing. Maybe it was needed at one time.

-- Chuck Moore, 1997

"If they are starting from the OS they have made the first mistake. The OS isn't going to fit on a floppy disk and boot in ten seconds."

-- Chuck Moore, 1999

Processor Design

Chuck's real love seems to be processor design.
Those Harris RTX2000 and RTX2010 chips used in so many space missions?
That's basically his chip!

No kidding.

Chuck, that brilliant rascal, has been designing hardware since 1983
starting with the Novix N400 gate array. An improved design was
sold to Harris to become the RTX chips.

Chuck designs processors with his own VLSI software, "OKAD", written in
500 lines of Forth, of course.

GreenArrays

"Programming a 144-computer chip to minimize power" (2013)

144 asynchronous computers on a chip. Idle cores use 100 nW. Active ones use 4 mW, run at 666 Mips, then return to idle. All computers running flat out: 550mW (half a Watt).

The future: sustainable low-energy computing and Forth?

"If you talk about molecular computers that are circulating in your bloodstream, they aren't going to have very much power and they aren't going to have very much memory and they aren't going to be able to use much energy.

-- Chuck Moore, Programming a 144-computer chip to minimize power, 2013

Forth-likes could have a strong future as we look towards:

• Tiny, ubiquitous computers
• Solar power
• Heavily constrained VMs

Chuck Moore is basically retired now, programming and toying with
software with no deadlines or clients.

It is now on us to take up the mantle of Forth, to champion the values
of ingenuity, elegance, efficiency, and simplicity.

Forth is...

The Legend Confirmed

I promised I would show you a magic trick at the end of this article.

Behold, a new definition for the integer 4:

: 4 12 ;


Which I shall now use in a sentence:

." The value of 4 is " 4 . CR

The value of 4 is 12


Tada!
