Overview​

This tutorial will walk you through building a 3×5 LED matrix controlled by a Raspberry Pi Pico using tscircuit.

Objectives of Building an LED Matrix​

Some practical applications of building an LED Matrix include:

• Signage – Building signs for events, products, etc.
• Data Visualization Tool – Displaying real-time data metrics like GitHub contributions, website traffic, or temperature readings through color intensity
• Interactive Notification System – Creating a physical notification system for emails, social media, or calendar events with customizable brightness levels

LED Matrix Requirements​

• The LED matrix must be WiFi-controllable
• The matrix layout pattern must be grid-based
• Each LED should be individually controllable for brightness and color

System Diagram​

The matrix connects to the Pico microcontroller via a data chain. The Pico connects to WiFi through the PICO_W module.
The components and connections between them are shown in the diagram below:

Schematic Capture​

Let’s import the Pico microcontroller and LED components by following the steps in the Importing from JLCPCB section.

We will follow the following steps to build the circuit step by step:

1. Import the Pico microcontroller Schematic
2. Import the LED Schematic
3. Chain two LEDs together
4. Chain many LEDs together
5. Connect the Pico to the LED matrix

Pico Schematic​

Schematic of the Pico microcontroller imported from JLCPCB is shown below:

LED Schematic​

We are using IC LEDs (specifically WS2812B), which have an RGB LED and control chip integrated into the same package. These IC LEDs offer several advantages over traditional RGB LEDs:

• Simplified Wiring – Only 4 pins needed (VDD, GND, Data In, Data Out) compared to 4+ pins for traditional RGB LEDs
• Serial Communication – LEDs can be daisy-chained together, requiring only one data pin from the microcontroller
• Individual Control – Each LED in the chain can be controlled independently for color and brightness

Chaining Two LEDs together​

To connect two LEDs together, we need to connect the data output DO of the first LED to the data input DI of the second LED. This creates a chain of LEDs.

Connecting Pico to the LED Matrix​

The Pico is connected to the LED matrix via a general purpose input/output (GPIO) pin in this example we are using GP6,
and the other pins of the Pico are connected to ground.

Chaining many LEDs together​

LED Matrix Layout​

We can connect multiple LEDs together by chaining them, but doing this for a large number of LEDs would be tedious.
Luckily, tscircuit has a helper function to create a grid of components. We will be using that helper function to create our matrix layout.

Here we are using the grid function to create a 3×5 LED matrix. The grid function takes in the number of columns and rows, and the spacing between the components.

Connecting the Pico to the LED matrix​

Here we are merging all the learnings from the previous examples to create a complete circuit. The Pico is connected to the LED matrix via the GP6 pin, and the other pins of the Pico are connected to ground.
The GP6 pin is connected to the data input DI of the first LED, and the data output DO of each LED is connected to the data input DI of the next LED in the chain.
While connecting the LEDs together, we are also connecting the GND and VDD pins of the LEDs to ground and 5V supply respectively.

Complete circuit is shown below:

PCB Layout​

We can translate our schematic into a PCB layout by specifying the physical positions of components on the board.

Here we are adding the positions of the components on the PCB:

• Pico microcontroller is added at pcbX={-15} pcbY={0} with a rotation of 90deg (Rotation is needed for the Pico to be in the correct orientation)
• LEDs are added at positions calculated by the grid function with a spacing of 8mm horizontally and 5mm vertically

Check out this circuit in our Playground.

Ordering the PCB​

You can order this PCB by downloading the fabrication files and uploading them to JLCPCB. Follow the instructions from here.

Controlling the LED Matrix​

The LED matrix can be controlled through a simple web interface that provides a visual grid for controlling individual LEDs. The control system includes:

1. Web Interface: A 3×5 grid interface where clicking each cell cycles through:

   • Off (Gray)
   • Red
   • Green
   • Blue

2. API Integration: The matrix state can be controlled and monitored through REST endpoints, making it easy to integrate with other applications.

3. Pico W Connection: The matrix connects to WiFi using the Pico W’s wireless capabilities, allowing for remote control through the web interface.

The complete implementation, including the web interface and Pico W code, is available in our LED Matrix Server repository.
