Implement Flash Attention Back End in SGLang – Basics and KV Cache

0x0. Introduction

In the past few weeks, we’ve implemented the Flash Attention Backend end-to-end in SGLang, which is now the default attention backend as of SGLang 0.4.6 release.

Throughout this journey, we learned a lot about how Attention Backend functions in modern LLM serving engines and developed a deeper understanding of Flash Attention itself.

In this series, we’ll walk through the implementation details, sharing insights that we hope will benefit anyone looking to implement their own attention backend in LLM serving engines.

Table of Contents for the series

This series will be split into 3 parts:

• Part 1: Basics, KV Cache and CUDA Graph Support (this post)
• Part 2: Speculative Decoding Support (coming soon)
• Part 3: MLA, Llama 4, Sliding Window and Multimodal Support (coming soon)

Latest Status of Attention Backend in SGLang

Benchmark Results

The benchmark results demonstrate that FA3 consistently delivers the highest throughput across all tested scenarios, outperforming both FlashInfer and Triton, especially as the input or output size increases.

We followed the same benchmark setup as this comment being used. Detailed benchmark results are available in this sheet

0x1. Background and Motivation

What is Flash Attention?

Flash Attention¹ is an IO-aware exact attention algorithm that uses tiling to reduce the number of memory reads/writes between GPU high bandwidth memory (HBM) and GPU on-chip SRAM.

It has been widely used in LLM inference and training, and is the default attention backend in modern serving engines like SGLang, vLLM, etc.

In most cases, it’s fine to treat it as a black box. However, by understanding its core logic, we can use it more intelligently.

I highly recommend this article² to understand the core logic of Flash Attention. And I also have a blog post about What is Flash Attention?, where I gave a brief introduction from code level.

How Attention Backend works in SGLang

SGLang Architecture

SGLang, as a modern LLM Serving Engine, has three major components (in logical view)³:

• Server Components: Responsible for handling the incoming requests and sending responses.
• Scheduler Components: Responsible for construct batches and send to Worker.
• Model Components: Responsible for the model inference.

Let’s focus on the model forward pass in the diagram above.

In step 8: the ModelRunner processes the ForwardBatch and calls model.forward to execute the model’s forward pass.

In step 9: model.forward will call each layer’s forward function, and the majority of the time is spent on the self-attention part. Hence the attention backend becomes the bottleneck of the model inference. In addition to performance, there are many different kinds of attention variants such as MHA, MLA, GQA, Sliding Window, Local Attention which require carefully optimized attention backend implementations.

Attention Backend Inheritance

Here is the inheritance relationship of the attention variants:

Let’s walk through the method in the AttentionBackend class to see what’s the backbone of the attention backend in SGLang.

1. forward(): When model.forward() is called, the forward method in the AttentionBackend will be called. It will be calling forward_extend() and forward_decode according to the forward_batch.forward_mode. In this blog, we only focus on EXTEND and DECODE mode.

2. forward_extend(): This method will be called for each layer when the forward_mode is EXTEND.

3. forward_decode(): This method will be called for each layer when the forward_mode is DECODE.

4. init_cuda_graph_state(): This method will be called during the server startup, it will preallocate those tensors which will be used in the CUDA Graph replay.

5. init_forward_metadata(): This method will be called when the model.forward() is called. It could precalculate some metadata for the entire model.forward() call, reused by each layer, this is critical for accelerating the model inference. What’s ironic is, this metadata is the most complicated part of the attention backend, once we set it up, the call of (text{softmax}left({mathbf{Q}mathbf{K}^top}right)mathbf{V}) computation is quite straightforward in this context.

6. init_forward_metadata_capture_cuda_graph: This method will be called during the server startup, CUDAGraphRunner will call this method during CUDA Graph Capture. CUDA Graph will stored in memory within CUDAGraphRunner’s self.graphs object.

7. init_forward_metadata_replay_cuda_graph: This method will be called during each layer’s forward_decode being called. It will setup the metadata for the forwade_decode call to make sure the CUDA Graph replay could be done correctly.

By far, we have covered all of the methods we need to implement for the attention backend. We will discuss it in following sections.

How KV Cache works in SGLang

You might be curious about why there is a req_to_token in each Attention Backend class. And I didn’t put it there accidentally. Actually, KV Cache, as the backbone of all LLM Serving Engines, is also very critical to Attention Backend, so let’s briefly take a look at it.

There are two-level memory pools to manage KV cache⁴.

req_to_token_pool

A map from a request to its tokens’ KV cache indices. And this is the req_to_token we mentioned in Attention Backend Diagram.

• Shape: Max Allowed Requests Number (being set by argument max-running-requests for the maximum number of requests to run concurrently) * Max Context Length for each request (being set by config model_config.context_len)
• Access:
  • Dim0: req_pool_indices identify the specific request
  • Dim1: token positions in req (starting from 0, 1, 2…), identify the specific token in the request
  • Value: out_cache_loc for token, it points to the KV cache indices associated with the token identified by Dim0 and Dim1

token_to_kv_pool

req_to_token_pool maintained the map between request to tokens KV cache indices, token_to_kv_pool further maps token from its KV cache indices to its real KV cache data. Note that, for different attention implementation, like MHA, MLA, Double Sparsity, token_to_kv_pool could have different implementation.

• Layout: Number of Layers * Max Allowed Tokens Number * Number of Head * Head Dimension
• Access:
  • Dim0: layer_id identify the specific layer
  • Dim1: out_cache_loc identify the specific KV cache indices (free slots)
  • Dim2: Head
  • Dim3: Head Dimension
  • Value: cache_k for k_buffer and cache_v for v_buffer, the real KV Cache Data

  Note that we normally retrieve the KV Cache for entire layer all together, because we would need all prior tokens’ KV in a request to do forward.

In attention backend, we only need to know what req_to_token_pool is and the rest of KV Cache management is transparent to the attention backend.

Let’s give an intuitive example of what req_to_token_pool looks like:

1. Assume we have 2 requests, and each request has 7 tokens.
2. Then req_to_token_pool is a tensor with shape (2, 7), where each entry maps a token in a request to its corresponding KV cache index.

    req_to_token_pool = [
        [1, 2, 3, 4, 5, 6, 7],
        [8, 9, 10, 11, 12, 13, 14]
    ]


   seq_lens is [7, 7].

3. After one forward_extend that adds a new token to each request, the req_to_token_pool will be updated to:

    req_to_token_pool = [
        [1, 2, 3, 4, 5, 6, 7, 15],
        [8, 9, 10, 11, 12, 13, 14, 16]
    ]


   seq_lens is [8, 8].

4. If the first request is complete and we run another decode for the second request, the req_to_token_pool will be updated to:

    req_to_token_pool = [
        [1, 2, 3, 4, 5, 6, 7, 15],
        [8, 9, 10, 11, 12, 13, 14, 16, 17]
    ]


   seq_lens is [8, 9].

With the above knowledge about KV Cache structure, we now have the foundation to implement our FlashAttention backend. The next step is to identify the correct parameters for the flash_attn_with_kvcache API to create a minimal working implementation.

For more details on KV Cache, refer to the Awesome-ML-SYS-Tutorial: KV Cache Code Walkthrough.

0x2. FlashAttention3 Backend Basic Implementation

OK, let’s start diving into the implementation of the FlashAttention backend in SGLang.

Here is the PR for the basic implementation: sgl-project/sglang#4680. I simplified the code in this blog for brevity and only focus on the core logic.

Tri Dao’s FlashAttention 3 Kernel API

Tri Dao has provided several public APIs for Flash Attention 3, the entry point is hopper/flash_attn_interface.py.

We opted for flash_attn_with_kvcache for two key reasons: it eliminates the overhead of manually assembling key-value pairs by accepting the entire page table directly, and it provides native support for Paged KV Cache (Page Size > 1), which is not available in flash_attn_varlen_func.

Let’s take a quick look at the flash_attn_with_kvcache API:

# we omiited some arguments for brevity
def flash_attn_with_kvcache(
    q,
    k_cache,
    v_cache,
    cache_seqlens: Optional[Union[(int, torch.Tensor)]] = None,
    page_table: Optional[torch.Tensor] = None,
    cu_seqlens_q: Optional[torch.Tensor] = None,
    cu_seqlens_k_new: Optional[torch.Tensor] = None,
    max_seqlen_q: Optional[int] = None,
    causal=False,
):
    """
    Arguments:
        q: (batch_size, seqlen, nheads, headdim)
        k_cache: (batch_size_cache, seqlen_cache, nheads_k, headdim) if there's no page_table,
            or (num_blocks, page_block_size, nheads_k, headdim) if there's a page_table (i.e. paged KV cache)
            page_block_size must be a multiple of 256.
        v_cache: (batch_size_cache, seqlen_cache, nheads_k, headdim_v) if there's no page_table,
            or (num_blocks, page_block_size, nheads_k, headdim_v) if there's a page_table (i.e. paged KV cache)
        cache_seqlens: int, or (batch_size,), dtype torch.int32. The sequence lengths of the
            KV cache.
        page_table [optional]: (batch_size, max_num_blocks_per_seq), dtype torch.int32.
            The page table for the KV cache. It will derived attention backend's req_to_token_pool.
        cu_seqlens_q: (batch_size,), dtype torch.int32. The cumulative sequence lengths of the query.
        cu_seqlens_k_new: (batch_size,), dtype torch.int32. The cumulative sequence lengths of the new key/value.
        max_seqlen_q: int. The maximum sequence length of the query.
        causal: bool. Whether to apply causal attention mask (e.g., for auto-regressive modeling).

    Return:
        out: (batch_size, seqlen, nheads, headdim).
    """

Initialization

With above information, now the mission is much clear, we just need to figure out those parameters for flash_attn_with_kvcache API, and we can achieve the bare minimum of FlashAttention backend.

Let’s start from the initialization of the FlashAttentionBackend class and FlashAttentionMetadata class.

@dataclass
class FlashAttentionMetadata:
    """Metadata which will be created once during model forward and reused across layers forward."""

    cache_seqlens_int32: torch.Tensor = None # Sequence Lengths in int32
    max_seq_len_q: int = 0 # Max Sequence Length for Query
    max_seq_len_k: int = 0 # Max Sequence Length for Key
    cu_seqlens_q: torch.Tensor = None # Cumulative Sequence Lengths for Query
    cu_seqlens_k: torch.Tensor = None # Cumulative Sequence Lengths for Key
    page_table: torch.Tensor = None # Page Table indicate the KV Indices for each sequence


class FlashAttentionBackend(AttentionBackend):
    """FlashAttention backend implementation."""

    def __init__(
        self,
        model_runner: ModelRunner,
    ):
        super().__init__()
        self.forward_metadata: FlashAttentionMetadata = None # metadata for the forward pass
        self.max_context_len = model_runner.model_config.context_len # max context length set by model config
        self.device = model_runner.device # device of the model (GPU)
        self.decode_cuda_graph_metadata = {} # metadata for accelerating decode process
        self.req_to_token = model_runner.req_to_token_pool.req_to_token # map from a request to its tokens' KV cache indices

Init Forward Metadata

def init_forward_metadata(self, forward_batch: ForwardBatch):
    """Initialize forward metadata during model forward and reused across layers forward

    Args:
        forward_batch: `ForwardBatch` object, contains the forward batch information like forward_mode, batch_size, req_pool_indices, seq_lens, out_cache_loc
    """
    # Initialize metadata
    metadata = FlashAttentionMetadata()
    # Get batch size
    batch_size = forward_batch.batch_size
    # Get original sequence lengths in batch
    seqlens_in_batch = forward_batch.seq_lens
    # Get device of the model, e.g: cuda
    device = seqlens_in_batch.device
    # Get sequence lengths in int32
    metadata.cache_seqlens_int32 = seqlens_in_batch.to(torch.int32)

    # Get max sequence length for key
    # Note that we use seq_lens_cpu to skip a device sync
    # See PR: https://github.com/sgl-project/sglang/pull/4745
    metadata.max_seq_len_k = forward_batch.seq_lens_cpu.max().item()
    # Get cumulative sequence lengths for key
    metadata.cu_seqlens_k = torch.nn.functional.pad(
        torch.cumsum(seqlens_in_batch, dim=0, dtype=torch.int32), (1, 0)
    )
    # Get page table, we cutoff by the max sequence length
    metadata.page_table = forward_batch.req_to_token_pool.req_to_token[
        forward_batch.req_pool_indices, : metadata.max_seq_len_k
    ]

    if forward_batch.forward_mode == ForwardMode.EXTEND:
        # Get sequence lengths in int32
        metadata.max_seq_len_q = max(forward_batch.extend_seq_lens_cpu)
        metadata.cu_seqlens_q = torch.nn.functional.pad(
            torch.cumsum(forward_batch.extend_seq_lens, dim=0, dtype=torch.int32), (1, 0)
        )
    elif forward_batch.forward_mode == ForwardMode.DECODE:
        # For decoding, query length is always 1
        metadata.max_seq_len_q = 1
            # Get cumulative sequence lengths for query
        metadata.cu_seqlens_q = torch.arange(
            0, batch_size + 1, dtype=torch.int32, device=device
        )

    # Save metadata, hence forward_extend and forward_decode could reuse it
    self.forward_metadata = metadata

Forward Extend and Forward Decode

In model forward, model_runner will call init_forward_metadata to initialize the metadata for the attention backend and then call the actual forward_extend and forward_decode. Hence the implementation of forward_extend and forward_decode is straightforward.

def forward_extend(
    self,
    q: torch.Tensor,
    k: torch.Tensor,
    v: torch.Tensor,
    layer: RadixAttention,
    forward_batch: ForwardBatch,
    save_kv_cache=True,
):
    # Get the KV Cache location from the forward batch
    cache_loc = forward_batch.out_cache_loc

    # Save the KV Cache for the new tokens
    if save_kv_cache:
        forward_batch.token_to_kv_pool.set_kv_buffer(layer, cache_loc, k, v)

    # Use precomputed metadata
    metadata = self.forward_metadata

    # Get the KV Cache for the previous tokens
    key_cache, value_cache = forward_batch.token_to_kv_pool.get_kv_buffer(layer.layer_id)
    o = flash_attn_with_kvcache(
        q=q.contiguous().view(-1, layer.tp_q_head_num, layer.head_dim),
        k_cache=key_cache.unsqueeze(1),
        v_cache=value_cache.unsqueeze(1),
        page_table=metadata.page_table,
        cache_seqlens=metadata.cache_seqlens_int32,
        cu_seqlens_q=metadata.cu_seqlens_q,
        cu_seqlens_k_new=metadata.cu_seqlens_k,
        max_seqlen_q=metadata.max_seq_len_q,
        causal=True, # for auto-regressive attention
    )

# forward_decode is identical to forward_extend, we've set the metadata differently in init_forward_metadata already

Until now, a bare minimum FlashAttention backend is implemented. We could use this backend to do the attention forward pass.

0x3. CUDA Graph Support

What is CUDA Graph?

CUDA Graph is a feature in NVIDIA’s CUDA platform that allows you to capture a sequence of GPU operations and replay them as a single, optimized unit. Traditionally, each GPU kernel launch from the CPU incurs some launch latency, and the CPU must coordinate each step in sequence. This overhead can become significant, especially for workloads with many small kernels.⁵

With CUDA Graph, you can record a series of operations (such as A, B, C, D, E in the diagram) into a graph, and then launch the entire graph in one go. This approach eliminates repeated CPU launch overhead and enables the GPU to execute the operations more efficiently, resulting in significant time savings. The diagram below illustrates this concept: The top part shows the traditional approach, where each kernel launch incurs CPU overhead. The bottom part shows the CUDA Graph approach, where the entire sequence is launched as a single graph, reducing CPU time and improving overall throughput.

Actually, I found that a lot of significant speedups in modern LLM Serving Engine comes from parallelizing multiple workloads and overlapping their execution. I can easily name a few examples:

• CUTLASS’s overlap of TMA and WGMMA⁶
• Flash Attention’s overlap of GEMM and Softmax⁷
• SGLang’s Zero-Overhead Batch Scheduler⁸

I believe there are more opportunities with this simple but effective philosophy, it make me really excited to see more and more cool projects being built on top of next generation hardwares.

How CUDA Graph works in SGLang

In SGLang, CUDA Graph’s capture and replay was done by CUDAGraphRunner class. Given that the framework already has a pretty decent design about how CUDAGraphRunner works with attention backend, we can focus on implementing those three methods:

• init_cuda_graph_state()
• init_forward_metadata_capture_cuda_graph()
• init_forward_metadata_replay_cuda_graph()

You can find the detailed flow of how CUDAGraphRunner works with attention backend in the diagram below:

Init CUDA Graph State

def init_cuda_graph_state(self, max_bs: int):
    """Initialize CUDA graph state for the attention backend.

    Args:
        max_bs (int): Maximum batch size to support in CUDA graphs

    This creates fixed-size tensors during server startup that will be reused during CUDA graph replay to avoid memory allocations.
    """
    self.decode_cuda_graph_metadata = {
        # Sequence Lengths in int32 (batch_size)
        "cache_seqlens": torch.zeros(max_bs, dtype=torch.int32, device=self.device),
        # Cumulative Sequence Lengths for Query (batch_size + 1)
        "cu_seqlens_q": torch.arange(
            0, max_bs + 1, dtype=torch.int32, device=self.device
        ),
        # Cumulative Sequence Lengths for Key (batch_size + 1)
        "cu_seqlens_k": torch.zeros(
            max_bs + 1, dtype=torch.int32, device=self.device
        ),
        # Page Table for token mapping from request to tokens' KV cache indices (batch_size, max_context_len)
        "page_table": torch.zeros(
            max_bs,
            self.max_context_len,
            dtype=torch.int32,
            device=self.device,
        ),
    }

It’s worth noting that, we found for metadata with tensor type, we need to be initialized first and then copy the value into the preallocated tensors, otherwise CUDA Graph will not work. For those metadata with scalar type (e.g: max_seq_len_q, max_seq_len_k), we can directly create new variable.

Prepare Metadata for Capture

def init_forward_metadata_capture_cuda_graph(
        self,
        bs: int,
        num_tokens: int,
        req_pool_indices: torch.Tensor,
        seq_lens: torch.Tensor,
        encoder_lens: Optional[torch.Tensor],
        forward_mode: ForwardMode,
    ):
        """Initialize forward metadata for capturing CUDA graph."""
        metadata = FlashAttentionMetadata()
        device = seq_lens.device
        batch_size = len(seq_lens)
        metadata.cache_seqlens_int32 = seq_lens.to(torch.int32)

        if forward_mode == ForwardMode.DECODE:
            metadata.cu_seqlens_q = torch.arange(
                0, batch_size + 1, dtype=torch.int32, device=device
            )
            metadata.max_seq_len_k = seq_lens.max().item()
            metadata.cu_seqlens_k = torch.nn.functional.pad(
                torch.cumsum(seq_lens, dim=0, dtype=torch.int32), (1, 0)
            )
            metadata.page_table = self.decode_cuda_graph_metadata["page_table"][
                req_pool_indices, :
            ]
        else:
            raise NotImplementedError(f"Forward mode {forward_mode} is not supported yet")

        self.decode_cuda_graph_metadata[bs] = metadata

To be honest, we don’t care too much about the actual value being set in init_forward_metadata_capture_cuda_graph because we will override in init_forward_metadata_replay_cuda_graph anyway. We just need to make sure the tensor shape is correct.

Prepare Metadata for Replay

def init_forward_metadata_replay_cuda_graph(
        self,
        bs: int,
        req_pool_indices: torch.Tensor,
        seq_lens: torch.Tensor,
        seq_lens_sum: int,
        encoder_lens: Optional[torch.Tensor],
        forward_mode: ForwardMode,
        seq_lens_cpu: Optional[torch.Tensor],
        out_cache_loc: torch.Tensor = None,
    ):
        """Initialize forward metadata for replaying CUDA graph."""
        # Get the sequence lengths in batch, we slice it out from the preallocated tensors
        seq_lens = seq_lens[:bs]
        # Get the sequence lengths in CPU, we slice it out from the preallocated tensors
        seq_lens_cpu = seq_lens_cpu[:bs]
        # Get the request pool indices, we slice it out from the preallocated tensors
        req_pool_indices = req_pool_indices[:bs]
        # Get the device of the model
        device = seq_lens.device
        # Get the metadata for the decode, which have been precomputed in init_forward_metadata_capture_cuda_graph() and initialized in init_cuda_graph_state()
        metadata = self.decode_cuda_graph_metadata[bs]

        if forward_mode == ForwardMode.DECODE:
            # Update the sequence lengths with actual values
            metadata.cache_seqlens_int32 = seq_lens.to(torch.int32)
            # Update the maximum sequence length for key with actual values
            metadata.max_seq_len_k = seq_lens_cpu.max().item()
            # Update the cumulative sequence lengths for key with actual values
            metadata.cu_seqlens_k.copy_(
                torch.nn.functional.pad(
                    torch.cumsum(seq_lens, dim=0, dtype=torch.int32), (1, 0)
                )
            )
            # Update the page table with actual values
            metadata.page_table[:, : metadata.max_seq_len_k].copy_(
                self.req_to_token[req_pool_indices[:bs], : metadata.max_seq_len_k]
            )

        else:
            raise NotImplementedError(f"Forward mode {forward_mode} is not supported yet")

        self.forward_metadata = metadata

Until now, a CUDA Graph supported FlashAttention backend is implemented!

0x4. Conclusion

In this article, we’ve explored several key components:

• The fundamentals of FlashAttention and its operational principles
• The architecture of Attention Backend in SGLang
• The implementation details of KV Cache in SGLang
• A step-by-step approach to implementing a basic FlashAttention backend
• The process of integrating CUDA Graph support for optimized performance

In our upcoming articles, we’ll delve into more advanced topics including Speculative Decoding (a challenging implementation that took us over 3 weeks!), as well as MLA, Llama 4, Multimodal capabilities, and more!

0x5. Thoughts about Open Source

This is my first significant contribution to a popular open source project, and I’m truly grateful for the community’s support and the maintainers’ guidance throughout this process.

For MLSys enthusiasts who want to begin their own journey in open source, I highly recommend joining the SGLang community. Here are some personal tips from my experience:

• You don’t need to be an expert to start contributing. Contributions to documentation, benchmarking, and bug fixes are all valuable and welcomed. In fact, my first two PRs were focused on documentation and benchmarking.
• Finding a good first issue can be challenging in established projects like SGLang. My approach was to follow a specific area closely (e.g: Quantization), monitor relevant PRs and issues, and offer assistance with smaller tasks by reaching out to PR authors through comments or Slack.
• Be accountable for your contributions and commitments. In open source communities, professional relationships are built on trust and reliability. Remember that most contributors are balancing open source work with full-time jobs, so respecting everyone’s time and effort is essential.
